Dimension GS-1116/GS-1124 Gigabit Switch
B Product Specifications
LED
SYSTEM
PWR (Green): On/Off
16/24 x 1000BASE-T ETHERNET PORTS
1000 (Green): On/Off
LNK/ACT (Link/Activity), (Green): On/Blinking/Off
FDX/COL (Full-duplex), (Yellow): On/Blinking/Off
MINI-GBIC SLOTS
LNK (Green): On/Off
ACT (Green): Blinking
Dimensions
440(W) x 161(D) x 44(H) mm
19” rack mountable enclosure
Power Supply 100 - 240V AC, 50/60Hz internal universal power supply
Power Consumption
GS-1116: 47W max
GS-1124: 69W max
Operating Temperature 0ºC to 45ºC (32ºF to 113ºF)
Operational Humidity 10% to 90% (Non-condensing)
EMI FCC Class A, CE, C-Tick for NZ/AUS
