6 ENGLISH

Switch action

► Fig.2: 1. Switch trigger

CAUTION: Before installing the battery car-

tridge into the tool, always check to see that the

switch trigger actuates properly and returns to

the "OFF" position when released.

To start the tool, simply pull the switch trigger. Tool

speed is increased by increasing pressure on the switch

trigger. Release the switch trigger to stop.

Reversing switch action

► Fig.3: 1. Reversing switch lever

CAUTION: Always check the direction of

rotation before operation.

CAUTION: Use the reversing switch only after

the tool comes to a complete stop. Changing the

direction of rotation before the tool stops may dam-

age the tool.

CAUTION: When not operating the tool,

always set the reversing switch lever to the neu-

tral position.

This tool has a reversing switch to change the direction

of rotation. Depress the reversing switch lever from the

A side for clockwise rotation or from the B side for coun-

terclockwise rotation.

When the reversing switch lever is in the neutral posi-

tion, the switch trigger cannot be pulled.

Speed change

► Fig.4: 1. Speed change lever

CAUTION: Always set the speed change lever

fully to the correct position. If you operate the

tool with the speed change lever positioned halfway

between the "1" side and "2" side, the tool may be

damaged.

CAUTION: Do not use the speed change lever

while the tool is running. The tool may be damaged.

Displayed

Number

Speed Torque Applicable

operation

1 Low High Heavy load-

ing operation

2 High Low Light loading

operation

To change the speed, switch o󰀨 the tool rst. Push the

speed change lever to display "2" for high speed or "1"

for low speed. Be sure that the speed change lever is

set to the correct position before operation.

If the tool speed is coming down extremely during the

operation with display "2", push the lever to display "1"

and restart the operation.

Adjusting the fastening torque

► Fig.5: 1. Adjusting ring 2. Graduation 3. Arrow

The fastening torque can be adjusted in 17 levels by

turning the adjusting ring. Align the graduations with the

arrow on the tool body. You can get the minimum fas-

tening torque at 1 and maximum torque at

The clutch will slip at various torque levels when set at

the number 1 to 16. The clutch is designed not to slip at

the marking.

Before actual operation, drive a trial screw into your

material or a piece of duplicate material to deter-

mine which torque level is required for a particular

application.

ASSEMBLY

CAUTION: Always be sure that the tool is

switched o󰀨 and the battery cartridge is removed

before carrying out any work on the tool.

Installing or removing driver bit/

drill bit

CAUTION: After inserting the driver bit, make

sure that it is rmly secured. If it comes out, do not

use it.

► Fig.6: 1. Sleeve 2. Open 3. Close

Turn the sleeve counterclockwise to open the chuck

jaws. Place the driver bit/drill bit in the chuck as far

as it will go. Turn the sleeve clockwise to tighten the

chuck. To remove the driver bit/drill bit, turn the sleeve

counterclockwise.

OPERATION

CAUTION: Always insert the battery cartridge

all the way until it locks in place. If you can see the

red indicator on the upper side of the button, it is not

locked completely. Insert it fully until the red indicator

cannot be seen. If not, it may accidentally fall out of

the tool, causing injury to you or someone around

you.

CAUTION: When the speed comes down

extremely, reduce the load or stop the tool to

avoid the tool damage.

Hold the tool rmly with one hand on the grip and the

other hand on the bottom of the battery cartridge to

control the twisting action.
