RESERATOR 1 Plus

5) Take out the power cable :

pull the Water Pump power cable out

through the Cable Hole.

6) Remove the cable fitting :

take the Cable Fitting out of the hole as

shown by using a screwdriver or an awl.

7) Remove the integrated water pump :

pull the Water Pump off the Sink Base

as shown.

8) Put on the Sealing Bolt B :

after removing the Cable Fitting, screw

on the Sealing Bolt B. Fasten tightly.

If this is not done properly it may cause

leakage.

9) Reassemble the sink base :

after all the steps are taken, reattach

the Sink Base to the main body firmly.

Take proper care in doing this as

leakage may result if not done correctly.

Sealing Bolt A

Water Pump

Power Cable

Cable Hole

Cable Fitting

Water Pump

Cable Fiting

Sealing Bolt B
