Tc Electronic G-SYSTEM [43/80] Menu mode pedals
![Tc Electronic G-SYSTEM [43/80] Menu mode pedals](/views2/1011825/page43/bg2b.png)
• Now use the PAGE Encoder to select parameters
and Encoder C to change their values.
A Brief Overview of the Pedals Menu
Parameter
Options
Volume Ctrl.: None/Vol/Exp/EncA/EncB/EncC
Volume Min: 0 to 100%
Volume Mid: 0 to 100%
Volume Max: 0 to 100%
GFX1 Vol. Type: Off/Pot/Momnt/Alt
GFX1 Exp. Type: Off/Pot/Momnt/Alt
CTRL Vol. Type: Off/Pot/Momnt/Alt
CTRL Exp. Type: Off/Pot/Momnt/Alt
Vol. Master: Preset/Global
Exp. Master: Preset/Global
GFX1 Vol. Calib.
GFX1 Exp. Calib.
CTRL Vol. Calib.
CTRL Vol. Calib.
Explanation of
Abbreviations:
Vol.: Volume – refers to the Volume connectors.
Exp.: Expression – refers to the Expression
connectors.
GFX1: The Processing Unit – GFX01.
CTRL: Control Board.
Calib.: Calibration.
Pot: Potentiometer – as in an expression pedal.
Momnt: Momentary pedal/switch.
Alt: Alternating pedal/switch.
Volume Ctrl. – Volume Control
The first displays show volume control parameters:
>> EFFECT COPIED <<
EDIT A EDIT B EDIT C
>> PRESET STORED <<
EDIT A EDIT B EDIT C
PEDALS MENU
Volume Ctrl.: Vol.
EDIT A EDIT B EDIT C
The G-System’s volume can be controlled via an
expression pedal connected to either the “Vol.” or to the
“Exp.” connectors on the GFX01 and the G-System.
The following options are available
:
• None: Volume is not controlled from any connected
expression pedals.
•Vol.: The expression pedal connected to the Vol.
connector on either the GFX01 or the Control Board
controls the Volume parameter.
• Exp.:
The expression pedal connected to the Exp.
connector on either the GFX01 or the Control Board
controls the Volume parameter.
• EncA, EncB, EnC: Encoder A, B or C controls the
Volume parameter.
The Volume parameter can be positioned in two
different places: before the Effects section or after
the Effects section. This is configured in the
Levels menu. Please refer to the “Volume
Position” section in this chapter to learn more
about these options and their consequences.
Min – Mid – Max
These parameter values define how the volume
parameter should respond to the the expression pedal’s
minimum, mid and maximum positions.
The default settings of Min, Mid and Max are 0%, 50%,
100% respectively and will let your connected expression
pedal act as a regular volume pedal that allows you to
turn the volume down entirely (Min Position) and also up
to maximum level (Max Position).
However, setting these parameters to e.g. 75%, 88% and
100% would give you a volume pedal which only
attenuates the signal partially when turned down.
MENU MODE – PEDALS
41
