Each of the switch functions has one or more additional
parameters that allow even further customization of their
functionality. The following table is an overview of the
functions available.
Function Style Param 3
None – –
Filter On/Off Toggle or Hold –
Comp On/Off Toggle or Hold –
Loop 1 On/Off Toggle or Hold –
Loop 2 On/Off Toggle or Hold –
Loop 3 On/Off Toggle or Hold –
Loop 4 On/Off Toggle or Hold –
Insert On/Off Toggle or Hold –
Relay Toggle or Hold –
Gate Toggle or Hold –
Boost On/Off Toggle or Hold –
Mod On/Off Toggle or Hold –
Pitch On/Off Toggle or Hold –
Delay On/Off Toggle or Hold –
Reverb On/Off Toggle or Hold –
EQ On/Off Toggle or Hold –
Preset Bank: none
A0 to A9 (Fact.) Preset 1 to 5
B0 to B9 (Fact.) Preset 1 to 5
0 to 39 (User) Preset:1 to 5
Tempo – –
Tuner Mute Toggle or Hold –
MIDI CC #0 to 119
None
No function.
Toggle/Hold
When T
oggle is selected, the selected parameter/effect is
switched on or off by hitting the switch once.
When Hold
is selected, the function assigned to the
switch is held as long as the switch is pressed, and it is
released when you release the switch.
Use the Hold option for effects that you just need
for a few seconds.
Tap Tempo
Allows you to tap the global G-System tempo.
Tuner Mute
Mutes the output while the Tuner is enabled.
Relay
Switch between Relay settings A and B (Toggle) or
temporarily activate setting B (Hold).
Preset
The following parameters allow you to use a switch to
recall any preset from the Factory or the User bank.
Two parameters must be set:
Bank:
Selects a bank. When set to “none”, the bank position is
defined using the UP/DOWN switches.
A0 to A9 and B0 to B9 are Factory banks.
Banks 0 to 39 are User banks.
Preset 1 to 5
Sets the preset to be recalled in the given bank.
MIDI CC
A switch can be assigned to send MIDI CC’s between 0
and 119 to G-Systems MIDI out. On the assigned MIDI
CC values will toggle between 0 and 127 every time the
switch is pressed.
