MIDI
Navigation
• Press EDIT and then MENU.
• Select MIDI using the PAGE Encoder and press
ENTER.
• Select parameters using the PAGE Encoder.
• Change parameters using Encoder C.
MIDI Channel
Range: Off, 1 to 16 or Omni
When Omni is selected, the G-System receives MIDI
information on all channels. When set to Off, the G-
System does not respond to any incoming MIDI data.
Program Change In
Range: On/Off
Determines whether the G-System should respond to
incoming MIDI program changes or not.
Program Change Out
Range: Off/On/On Map
This parameter and the Prg. Map parameter concern the
MIDI program change information sent on MIDI out when
a preset is recalled on G-System.
Of
f: No program changes are sent on MIDI out.
On:
Program changes are sent on MIDI out when presets
are recalled. Adjacent to the sent program change, an
MSB value is also sent. The MSB (Most Significant
Bit=Ctrl#0) followed by a valued is used to select a
preset bank on the receiving MIDI device. Note that not
all MIDI devices are designed to read the MSB.
G-System has 300 preset locations. 100 factory presets
and 200 user preset locations.
MIDI MENU
MIDI Channel: 1
EDIT A EDIT B EDIT C
>> EFFECT COPIED <<
EDIT A EDIT B EDIT C
>> PRESET STORED <<
EDIT A EDIT B EDIT C
- When recalling the 100 factory presets in banks A0 to
B19, MSB value 0 followed by program changes 0-99 is
sent on MIDI out.
- When recalling the 100 user presets in user banks 00
to 19, MSB value 1 followed by program changes 0-99 is
sent on MIDI out.
- When recalling the 100 user presets in user banks 20
to 39, MSB value 2 followed by program changes 0-99 is
sent on MIDI out.
On Map:
Use this setting to activate the Prg. Map - see next
paragraph.
Prg. Map:
Via the MIDI Program Map you are able to select which
program change (1-128) should be sent on MIDI out
when recalling a user presets. To activate the Prg. Map
function the Program Change Out parameter must be set
to “On map” to activate the Prg. map.
In the example above Prg. Change no. 6 will be sent on
MIDI out when preset 2 in User bank 00 is recalled on
the G-System. The Factory bank holds 100 presets.
When recalling Factory presets program changes 1 to
100 will be sent on MIDI out.
When the Prg. Map function is used NO MSB (bank
select messages) is sent on MIDI out.
Prg. Map Reset
Press ENTER to reset the Program Map.
SysEx ID
Range: 0 to 126
Sets the G-System’s SysEx ID for identification in larger
MIDI setups.
>> EFFECT COPIED <<
EDIT A
EDIT B EDIT C
>> PRESET STORED <<
EDIT A
EDIT B EDIT C
MIDI MENU
PrgMap: 00-2 to 6
EDIT A
EDIT B EDIT C
MENU MODE – MIDI
46
