21
7 Hand blender
8 Cover for the hand blender connection
Instructions
• For optimum results use high-walled vessels that are not
too large.
• In order to avoid splashing, always insert the rods fully into
the food being mixed before you switch the mixer on.
• Pay attention to the slowing down of the motor after shutting
off.
• The device is only designed for small quantities! You should
therefore onlyll the maximum quantities stated in the table
into a container!
• To turn off the device, switch the speed setting (2) to “0” (see
Fig. B).
Hand blender (7)
Chop up large pieces of solid food before mashing (max. Ø 1.5
cm) and add a little liquid.
CAUTION:
Only use the hand blender at settings 1 - 2. Do not use the
hand blender at settings 3 - 5 or turbo. This could result in
damage to the appliance.
Turbo operation (3)
This is for switching to maximum speed for a short time. Press
at short intervals for pulsed mode operation.
CAUTION:
Do not use this function for more than one minute.
Initial Operation
Preparation
• Take out all the parts carefully out of the packing.
WARNING:
Please be extremely careful when removing the foil from
the blade of the hand mixer!
• Clean the device before using it for therst time as de-
scribed in “Cleaning”.
Mounting the storage bowl
The storage bowl can be mounted to a wall. To do so, please
proceed as follows:
• Check whether no electric cables or water pipes are located
in the intended position.
• Drill two holes, with a diameter of 5 mm at a distance of
90 mm horizontally, into the wall.
• Push the supplied dowels into the holes.
• Twist the supplied screws into the dowels so that the
screws still protrude out of the wall by approx. 5 mm.
• Hang the storage bowl onto the screws using the slits on
the rear side.
Electrical connection
Check whether the electrical voltage that you intend to use is
the same as that of the machine. You can nd this information
on the nameplate.
How to use the Kneader hooks/beater
1. Turn the power level selector switch (2) to “0” and ensure
that the mixer has been disconnected from the mains.
2. Press the end of the kneader hooks/beater into the cor-
responding mixer openings until the hooks click into place.
While pressing, turn slightly in order to facilitate the whole
operation
NOTE:
The kneading hook with the curved washer on the shaft
can only be inserted on the left-hand side of the mixer
when viewed from the bottom.
3. Connect the device to a duly installed 230 V/50 Hz protec-
tive contact socket.
4. The hand mixer can be used at various speeds set with the
speed regulator (2).
5. In order to release the kneading hook/whisk turn the power
level selector switch to “0” and ensure that the mixer has
been disconnected from the mains.
6. Press the button (1) to release the kneading hook/whisk.
Remove the device by turning it slightly.
Using the Hand Blender
1. Turn off the appliance and disconnect it from the power
outlet.
2. Slide the cover (8) for the connection of the hand blender (7)
upwards into the housing so that the slot is exposed.
3. Fit the hand blender (7) into the opening and secure it by
turning it anti-clockwise (see Fig. D).
4. Plug the connector into the power outlet.
5. Immerse the hand blender up to a maximum of ¾ deep into
a lled mixing bowl.
6. The hand mixer can be used at various speeds set with the
speed regulator (2).
CAUTION:
Only use the hand blender in the settings 1 - 2. Do not
use the hand blender at settings 3 - 5 or turbo. This could
result in damage to the appliance.
7. When you would like to stop mixing, turn the power level
selector switch to “0” and unplug the device from the mains.
8. To detach the hand blender from the motor housing, turn it
clockwise and carefully pull it off.
