Yamaha YQ50 AEROX (1997) [20/192] Maintenance specifications
![Yamaha YQ50 AEROX (1997) [20/192] Maintenance specifications](/views2/1121366/page20/bg14.png)
SPEC
2-5
MAINTENANCE SPECIFICATIONS
Automatic centrifugal clutch:
Clutch shoe thickness 2.0 mm
<Wear limit> <1.0 mm>
Clutch shoe spring free length 29.9 mm
Clutch housing inside diameter 107.0 mm
<Wear limit> 107.4 mm
Clutch-in revolution 3.950 ~ 4.450 r.p.m.
Clutch-stall revolution 6.900 ~ 7.700 r.p.m.
V-belt:
Width 16.5 mm
<Wear limit> <15.7 mm>
Transmission:
Main axle runout limit 0.08 mm
Drive axle runout limit 0.08 mm
Kick starter:
Type Ratchet type
Kick clip tension 0.15 ~ 0.25 kg
Carburetor:
I.D mark DELLORTO PHBN 12 HS
Main jet (M.J) #86 (F)(B)(P)(I)(E)
#85 (CHE)
#74 (NL)
Main air jet (M.A.J) ø1.5
Jet needle (J.N) A21 - 2/5 (F)(B)(P)(I)(E)
A12 - 3/5 (D)(CHE)
A20 - 3/5 (NL)
Needle jet (N.J) 210 GA (F)(B)(P)(I)(E)(D)
209 GA (CHE)
208 GA (NL)
Cutaway (C.A) 3.0
4.0 (CHE)
Pilot jet (P.J) #36
#34 (CHE)
Bypass 1 (B.P.1) 0.8
Air screw (A.S) 1 3/8 ± 1/8 (F)(B)(P)(I)(E)
1 3/4 ± 1/8 (D)
1 5/8 ± 1/8 (NL)
2 ± 1/8 (CHE)
Valve seat size (V.S) 1.2
Starter jet (G.S.1) #45
Engine idle speed 1600 ~ 2000 rpm
Reed valve:
Valve stopper height 6.0 ~ 6.4 mm
Reed valve clearance Less than 0.2 mm
Lubrication system: Autolube pump
Stroke 2.62 mm (F)(B)(P)(I)(E)
2.5 mm (D)(NL)(CHE)
Bore 0.5 mm
Model YQ50
