21
NOTE:
CHK
ADJ
PERIODIC MAINTENANCE/LUBRICATION INTERVALS
NO
ITEM
CHECK OR MAINTENANCE JOB
ODOMETER READING ( 1,000 km)
ANNUAL
NO
.
ITEM
CHECK
OR
MAINTENANCE
JOB
1 10 20 30 40
CHECK
15 * Steering bearings
S Check bearing play and steering for
roughness.
√ √ √ √ √
gg
S Lubricate with lithium-soap-based grease. Every 20,000 km
16 * Chassis fasteners
S Make sure that all nuts, bolts and
screws are properly tightened.
√ √ √ √ √
17
Sidestand,
centeratand
S Check operation.
S Lubricate.
√ √ √ √ √
18 * Sidestand switch S Check operation. √ √ √ √ √ √
19 * Front fork S Check operation and for oil leakage. √ √ √ √
20 *
Shock absorber
assemblies
S Check operation and shock absorbers for
oil leakage.
√ √ √ √
21 * Carburetors
S Check starter (choke) operation.
S Adjust engine idling speed and
synchronization.
√ √ √ √ √ √
22 Engine oil
S Change.
S Check oil level and vehicle for oil leakage.
√ √ √ √ √ √
23
Engine oil filter
element
S Replace. √ √ √
24 *
Front and rear
brake switches
S Check operation. √ √ √ √ √ √
25
Moving parts and
cables
S Lubricate. √ √ √ √ √
26 *
Lights, signals
and switches
S Check operation.
S Adjust headlight beam.
√ √ √ √ √ √
D The air filter needs more frequent service if you are riding in unusually wet or dusty areas.
D Hydraulic brake and clutch service.
S Regularly check and, if necessary, correct the brake and clutch fluid levels.
S Every two years replace the internal components of the brake master cylinders and calipers as
well as clutch master and release cylinders, and change the brake and clutch fluids.
S Replace the brake and clutch hoses every four years and if cracked or damaged.
