2
SPEC
GENERAL SPECIFICATIONS
Model XJR1300 (P)
Tire:
Type
Size front
rear
Manufacturer front
rear
Type front
rear
Tubeless
120/70ZR17 (58W)/
120/70ZR17 M/C (58W)
180/55ZR17 (73W)/
180/55ZR17 M/C (73W)
MICHELIN/DUNLOP
MICHELIN/DUNLOP
MACADAM90X E/D220F ST M
MACADAM90X E/D220 ST M
Tire pressure (cold tire):
Maximum load-except motorcycle
Loading condition A *
front
rear
Loading condition B *
front
rear
High-speed riding
front
rear
203 kg
0 X 90 kg
250 kPa (2.5 kg/cm
2
, 2.5 bar)
250 kPa (2.5 kg/cm
2
, 2.5 bar)
90 X 203 kg
250 kPa (2.5 kg/cm
2
, 2.5 bar)
290 kPa (2.9 kg/cm
2
, 2.9 bar)
250 kPa (2.5 kg/cm
2
, 2.5 bar)
290 kPa (2.9 kg/cm
2
, 2.9 bar)
*Load is the total weight of cargo, rider, passenger, and accessories.
