24
E
23
If you select ON and press the ENTER button, the MOTION
DET screen will come up. You can set the AREA to which the
Motion Detection function will be applied to either PRESET or
USER. If you set the AREA option to PRESET, the Motion
Detection function will be applied to the areas preset as factory
defaults. If you set the AREA option to USER and press the
ENTER button, you can change the area size and position and
select the area where you want to apply the Motion Detection
function. You can specify the size of the area by using the UP,
DOWN, LEFT, and RIGHT buttons. If the area is not flashing,
press the ENTER button. When the area starts flashing, use the
UP, DOWN, LEFT and RIGHT buttons to specify the location of
the area. Use the ENTER button and the UP, DOWN, LEFT,
and RIGHT buttons to specify the size of the area and to
position the area. Press the ENTER button again to exit the
AREA setting menu. You can use the SENSITIVITY option to
set the motion detection sensitivity. The higher the setting, the
more sensitive the motion detection.
SIZE
LOCATION
CAMERA ID OFF
IRIS ALC...
SHUTTER OFF
AGC LOW
WHITE BAL ATW1
FOCUS MODE AF
MOTION DET ON...
COLOR/BW COLOR
PRIVACY ...
SPECIAL ...
PRESET ...
EXIT QUIT
(MOTION DET)
AREA PRESET...
SENSITIVITY L---I---H
RET
(MOTION DET)
AREA USER...
SENSITIVITY L---I---H
RET
Press the
ENTER
button.
Press the
ENTER
button.
❙
FOCUS MODE
The FOCUS MODE menu performs AF(Auto Focus),
MF(Manual Focus), and ONEAF(One Auto Focus).
✔
AF : Focuses automatically by continuously monitoring the
screen in AUTO FOCUS mode. It does not process the
FOCUS button input because it focuses automatically
during ZOOM.
✔
MF : You can manually adjust the focus.
✔
ONEAF : Focusing will take about 5 seconds in ONEAF
mode. When turned off, it is same to the MF
mode.
CAMERA ID OFF
IRIS ALC...
SHUTTER OFF
AGC LOW
WHITE BAL ATW1
FOCUS MODE AF
MOTION DET OFF
COLOR/BW COLOR
PRIVACY OFF
SPECIAL ...
PRESET ...
EXIT QUIT
❙
MOTION DET
MOTION DET detects any motion. Set up this function
during no human movement to detect break-in. Once
detected, an ALARM signal will be given for 5 seconds. As
MOTION DET detects any motion, so it can set up the
motion detection sensitivity. Select ON... and press [ENTER]
and the MOTION DET submenu screen will appear.
❖
MOTION detection function operates based on the
brightness change within the setup region. Therefore,
erroneous operation may occur depending on the brightness
difference between the background and the object that is
being taken, or the status of the area setup, etc.
00544A_C4207(P)-E+R+P 6/5/06 10:29 AM ˘` 23
