30
E
29
- C-LEVEL: It is used to set the levels for the Burst signal
and the entire colour signal of the video signal.
- OTHER SET
In OTHER SET menu, you can adjust LANGUAGE, CTRL
TYPE, ZOOM SPEED, D-ZOON, RS-485, SYSTEM
INFO..., and V-SYNC function, DISPLAY ZOOM etc. When
you press [ENTER] key from OTHER SET menu, the
OTHER SET additional menu screen appear.
- LANGUAGE : Selects English/Russian/Polish OSD menu.
- CTRL TYPE : By inputting the wire remote port, you may
set up the mode, A, B, C, or D.
- ZOOM SPEED : Use [Left, Right] key in the ZOOM SPEED
menu to set the speed as follows.
- ZOOM SPEED 1 : About 17Sec. from X 1 to X 32(Slowest)
- ZOOM SPEED 2 : About 10Sec. from X 1 to X 32(Slow)
- ZOOM SPEED 3 : About 6Sec. from X 1 to X 32(Fast)
- ZOOM SPEED 4 : About 3Sec. from X 1 to X 32(Fastest)
- D-ZOOM : Sets up the Digital Zoom magnification ratio up
to x10.
- RS-485 : Sets up RS-485 Communication Protocol,
Address, and Baud Rate.
Code
A
B
C
D
Tele
-6V
-6V
+6V
+6V
Wide
+6V
+6V
-6V
-6V
Far
+6V
-6V
+6V
-6V
Near
-6V
+6V
-6V
+6V
❖
V-SYNC menu is only available in SCC-C4307.
❖
When a DC power is supplied, V-SYNC menu will be displayed
as --- and you cannot make any settings.
(OTHER SET)
LANGUAGE ENGLISH
CTRL TYPE A
ZOOM SPEED 4
D-ZOOM OFF
RS-485 ...
SYSTEM INFO ...
V-SYNC INT
DISPLAY ZOOM OFF
RET
(SPECIAL)
POSI/NEGA +
DIS OFF
REVERSE OFF
DETAIL (0)--I-
Y-LEVEL (0)I--------
C-LEVEL (0)I--------
OTHER SET ...
RET
- SYSTEM INFO : You can confirm settings related to the
RS-485 communication, product serial number, and the
software version.
- V-SYNC : INT shall be selected to use internal
synchronization. LINE... is used to synchronize several
camera phases for the multi camera operation by using an
external signal(AC signal). As there may be a slight deviation
between sets, adjusts PHASE to overcome this handicap.
When you use AC power source, V-SYNC is available.
Select LINE... and press [ENTER] and the PHASE control
submenu will appear. The PHASE control ranges from -106H
to +106H as for NTSC and from -138H to +138H as for PAL.
Press the
ENTER
button.
(OTHER SET)
LANGUAGE ENGLISH
CTRL TYPE A
ZOOM SPEED 4
D-ZOOM OFF
RS-485 ...
SYSTEM INFO ...
V-STNC INT
RET
(RS-485)
PROTOCOL SAMSUNG
BAUD RATE 9600
ADDRESS 0
RET
Press the
ENTER
button.
(OTHER SET)
LANGUAGE ENGLISH
CTRL TYPE A
ZOOM SPEED 4
D-ZOOM OFF
RS-485 ...
SYSTEM INFO ...
V-STNC INT
RET
Press the
ENTER
button.
(SPECIAL)
CTRL TYPE A
POSI/NEGA +
ZOOM SPEED 1
DIS OFF
D-ZOOM OFF
REVERSE OFF
RS-485 ...
V-SYNC LINE...
LANGUAGE ENGLISH
DETAIL (0)--I-
RET
(LINE LOCK)
PHASE (000)----I----
RET
(SYSTEM INFO)
ROM VER 1.000
EEP VER 1.000
PROTOCOL SAMSUNG
ADDRESS 0
TYPE RS-485, HALF
BAUD RATE 9600
SERIAL NO 000000000000000
RET
00544A_C4207(P)-E+R+P 6/5/06 10:29 AM ˘` 29
