Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

1 Weight Stack Frame 1 27 Guide Rod Φ19*1177 2

2 Main Fram 1 28 Aluminium Grip Cap 2

3 Rear Cross Brace 1 29 Aluminium Grip Ring 2

4 Sway Pulley Bracket 1 30 Big Aluminium Cap Φ60*Φ10.5*10.9 4

5 Foam Frame 1 31 Aluminium Ring Φ90*Φ26.2*8.5 4

6 Left Pull Arm 1 32 Aluminium Cap Φ50*Φ10.5*8 6

7 Right Pull Arm 1 33 Bearing Φ50.8*Φ25.4*15.9 6

8 Bottom Cross Brace 1 34 Nut M10 4

9 Rod Φ25.4*855 2 35 Bushing Φ38*Φ25.4*18 2

10 Upper Frame 1 36 Weight Rubber Bumper 2

11 Scaleboard 1 37 Elliptical Rubber Bumper 1

12 Foam Axle Φ25.4*72.5 1 38 Pulley Cover 5

13 Grip STΦ30*Φ22*355 2 39 Tie Rod End M16*Φ16 2

14 Pivot Axle Φ25.4*144 2 40 Tie Rod End M16*Φ16(L) 2

15 Pivot Axle Φ25.4*158 1 41 Cable End Φ25.4*Φ10*37 1

16 Pin 1 42 Spacer Φ10*Φ14*20 1

17 Rubber Counterweight 2 43 Button Φ8*Φ20*23 8

18 Adjustable Foot plate 4 52 Rubber Plug Φ29*Φ19*10 2

19 Top Plate 1 53 Rubber Sleeve Φ17*10.5 2

20 Selector Pin W/Coil 1 54 Flat Washer Φ13*Φ24*1.5 2

21 Short Foam Φ140*182 2 56 Flat Washer Φ11*Φ20*2 40

22 Foam Tube Φ25.2*516 1 57 Flat Washer Φ9*Φ16*1.6 2

23 4.5" Pulley 6 58 Hex Nut M16(L) 2

24 Cable 1 59 Hex Nut M16 2

25 Seat Pad 1 60 Nylon Lock Nut M10 20
