─ 6 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

61 Nylon Lock Nut M12 1 86 Lube 1

62 Nylon Lock Nut M8 2 90 Flat Head Cap Screw M10*25 6

63 Flat Head Cap Screw M10*30 6 94 Front Shroud 1

64 Hex Head Bolt M10*100 2 95 Rear Shroud 1

65 Hex Head Bolt M10*135 4 98 Rivet Nut M8 2

66 Hex Head Bolt M10*75 2 100 Hex Head Bolt M8*30 2

67 Hex Head Bolt M10*45 1 101 Spring Washer Φ8 2

68 Hex Head Bolt M10*50 3 102 Flat Washer Φ9*Φ22*1.6 2

69 Hex Head Bolt M10*80 2 103 Shroud clip 12

70 Hex Head Bolt M12*100 1 104 Plastic Cover 1

71 Hex Head Bolt M10*25 4 105 4.5" Pulley for Sensor 1

72 Hex Head Bolt M10*30 4 106 Plate for sensor 1

Socket Head Cap Screw M10*50

4 107 Part Pulley Cover 2

Socket Head Cap Screw M16*40

4 108 Top Front Shroud 1

75 Socket Head Cap Screw M8*20 2 109 Support 1

76 Socket Set Screw M8*8 2 110 Top Cover 1

77 Screw M5*12 9 111 Left Plug 1

78 Rivet Nut M5 5 112 Right Plug 1

79 Socket Set Screw 10-32*3.2 4 113 Philips Screw M3*8 4

80 Hex Key S=12 1 114 Sensor 2

81 Hex Key S=3/32" 1 115 Console PCB 1

82 Hex Key S=4 1 116 Cover for Magnetic Iron 1

83 Hex Key S=6 1 117 Magnetic Iron 2

84 Hex Key S=8 1 118 Screw ST2.9*9.5 2

85 Wrench Φ6*117 1 119 Hex Head Bolt M10*55 1
