Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

1 Weight Stack Frame 1 33 Big Collar 4

2 Main Frame 1 34 Collar Φ65.6*Φ50.5*12.7 1

3 Handle 1 35 Roller Φ140*466 2

4 Pivot Arm 1 36 Top Plate 1

5 Cam 1 37 Selector Pin W/Coil 1

6 Bottom Cross Brace 1 38 Ball 1

7 Swing Tube 1 39 Pin End 1

8 Adjustable Tube 1 40 Pin Pole 1

9 Main Bracket 1 41 Spring Φ1.2*Φ12.9*70 1

10 Rear Cross Brace 1 42 Spring Φ1.2*Φ13*38.6 1

11 Back Pad Support 1 43 Button 10

12 Seat Pad 1 44 Rear Shroud 1

13 Back Pad 1 46 Front Shroud 1

14 Cable 1 51 Bushing 2

15 Adjustable Foot Plate 4 52 Plate 2

16 Adjustable Support 1 53 Nut 2

17 Adjustable Handle 1 54 Plastic Tube Guide 2

18 Flange 2 55 Plug RT50*100 5

19 Counter Poise Block 1 56 Grip 2

21 Main Shaft Φ25*335.4 1 57 Yellow Grip 1

22 Guide Rod 2 58 Adjustable Support Sleeve 1

23 Scaleboard 1 59 Weight Rubber Bumper Φ63.5*Φ19*25.4 2

24 Swing Tube Scaleboard 1 60 Little Bumper Φ17*10.5 4

25 Seat Pad Plate 1 61 Bumper Φ32*Φ25.4*40 1

26 Bearing Φ50.8*Φ25.4*15.9 6 62 Plastic Cap Φ30 2

27 Pin 1 63 Plug Φ50.8 1

28 4.5" Pulley 2 64 Washer Φ27.6*Φ12.8*3.5 2

29 Aluminum End Cap Φ50*Φ10.5*8 3 65 Rivet Nut M8 2

30 Aluminum End Cap Φ60*Φ10.5*10 1 67 Hex Head Bolt M12*35 4

31 Aluminium Grip Cap 2 69 Hex Head Bolt M10*135 2

32 Aluminium Grip Ring 2 70 Hex Head Bolt M10*100 2
