─ 6 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

57 Inner Spring Lock 4 88 Hex Nut M10 1

59 Aluminium Grip Cap 2 89 Nut 2

60 Aluminium Grip Ring 2 90 Flat Head Cap Screw M8*20 6

61 Button 8 91 Hex Key s=3 1

62 Plastic Cover 1 92 Hex Key s=4 1

67 Little Bumper 2 93 Hex Key s=5 1

68 Little Adjustable Ring 1 94 Hex Key s=6 1

69 Plug Φ32 2 95 Hex Key s=3/32" 1

70 Hex Head Bolt M10*100 4 96 Wrench 1

71 Hex Head Bolt M10*90 4 97 Lube 1

73 Hex Head Bolt M10*50 11 99 Rivet Nut M8 2

74 Socket Head Cap Screw M8*20 2 100 Rubber Plug Φ29*Φ19*10 2

75 Hex Head Bolt M10*25 7 101 Hex Head Bolt M8*30 2

76 Socket Head Cap Screw M4*15 2 102 Spring Washer Φ8 2

77 Button Head Cap Screw M8*20 1 103 Flat Washer Φ9*Φ22*1.6 2

78 Button Head Cap Screw M6*12 12 112 Left Pulley Shroud 1

79 Flat Head Cap Screw M10*30 10 113 Right Pulley Shroud 1

80 Philips Screw M5*12 11 115 Philips Screw M3*8 4

81 Flat Washer Φ6.6*Φ18*1.6 12 117 Console PCB 1

82 Flat Washer Φ11*Φ20*2 41 119 Magnetic Iron 8

83 Flat Washer Φ9*Φ16*1.6 9 123 Sensor 2

84 Socket Set Screw 10-32*3.2 4 124 Plate for Sensor 1

85 Nylon lock Nut M8 10 125 Cover for Magnetic Iron 1

86 Nylon lock Nut M10 15 126 Flat Washer Φ5.5*Φ10*1 2

87 Rivet Nut M5 7
