Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

1 Weight Stack Frame 1 27 Shroud clip 12

2 Main Frame 1 28 Adjustable Foot plate 4

3 Upper Cross Link Weldment 1 29 Selector Pin W/Coil 1

4 Bottom Cross Brace 1 30 Top Plate 1

5 Rotary Arm Frame 1 31 Split Pin Φ11*76 1

6 Handle Frame 2 32 Nut 2

7 Pulley Bracket 1 39 Front Support 1

8 Seat Pad Support 1 40 Rivet Nut M5 5

9 Counter Poise Block 1 45 Button Φ8*Φ20*23 8

10 Cable 1 46 Aluminium Shield 4

11 Main Shaft Φ25.4*239 1 47 Plastic Tube Guide 2

13 Adjustable Support 1 48 Weight Rubber Bumper 2

14 Guide Rod Φ19*1177 2 49 4.5" Pulley 3

15 Weight Stack Space 237 2 50 3.5" Pulley 2

17 Back Pad 1 51 FOAM Pad 2

18 Seat Pad 1 52 Aluminium Cap Φ60*Φ10.5*10.9 2

19 Adjustable Support Sleeve 1 53 Plate for sensor 1

20 Spring 1 54 4.5" Pulley for Sensor 1

21 Plug RT50*100 1 56 Cushion 1

22 Pulley Cover 6 57 Screw M5*12 9

23 FOAM Tube Φ25*2.5*516 1 58 Hex Head Bolt M10*135 7

24 1" Bearing 2 59 Hex Head Bolt M8*30 2

25 Aluminium Cap Φ50*Φ10.5*8 2 60 Hex Head Bolt M10*100 2

26 Bush Φ38*Φ25.4*25.4 2 61 Hex Head Bolt M10*45 1
