Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

63 Hex Head Bolt M10*50 1 89 Flat Head Cap Screw M10*25 2

64 Hex Head Bolt M10*30 6 91 Front Shroud 1

65 Hex Head Bolt M10*25 2 92 Rear Shroud 1

66 Flat Head Cap Screw M10*30 2 95 Rubber Plug Φ29*Φ19*10 2

Button Head Cap Screw M10*55

1 96 Flat Washer Φ9*Φ22*1.6 2

68 Button Head Cap Screw M8*55 1 97 Spring Washer Φ8 2

69 Socket Head Cap Screw M8*30 1 98 Tapped Hole Nut M8 2

Socket Head Cap Screw M10*20

2 101 Hex Head Bolt M10*75 2

Socket Head Cap Screw M10*50

3 102 Socket Set Screw M6*15 2

72 Button Head Cap Screw M6*12 2 103 Hex Key s=3 1

73 Flat Washer Φ11*Φ20*2 37 105 Weight Plate 5LBS 2

74 Flat Washer Φ9*Φ16*1.6 2 106 Weight Plate 10LBS 3

75 Nylon lock Nut M10 17 107 Weight Plate 15LBS 10

76 Nylon lock Nut M8 1 123 Plastic Cover 1

77 Spacer Φ10*Φ14*20 1 124 Sensor 2

63 Hex Head Bolt M10*55 1 125 Philips Screw M3*8 4

79 Socket Set Screw M8*8 2 126 Console PCB 1

80 Hex Nut M6 2 127 Cover for Magnetic Iron 1

81 Hex Key s=4 1 128 Magnetic Iron 4

83 Hex Key s=5 1 129 Screw ST2.9*9.5 2

84 Hex Key s=8 1 132 Top Front Shroud 1

86 Wrench Φ6*117 1 133 Top Cover 1

87 Lube 1 134 Left Plug 1

88 Bush Φ27.8*Φ25.4*28.6 2 135 Right Plug 1
