Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

1 Weight Stack Frame 1 45 Shroud clip 8

2 Left Support 1 48 Weight Rubber Bumper 2

3 Right Support 1 49 Grip 2

4 Left Cross Brace 1 50 Selector Pin W/Coil 1

5 Right Cross Brace 1 51 3.5" Pulley 1

7 Glide Support 1 52 6" Pulley 2

8 Nether Cross Brace 1 53 Nut 2

9 Left Handle 1 54 Flat Washer Φ11*Φ20*2 41

11 Handle 2 55 Nylon lock Nut M10 19

12 Guide Rod 2 56 Hex Head Bolt M10*130 4

13 Leg Pad 1 57 Split PinΦ11*76 1

14 Doughnut Baffle 2 58 Hex Head Bolt M10*80 7

15 Guide Rod Φ19*1477 2 59 Hex Head Bolt M10*50 3

16 Pulley Bracket 1 60 Hex Head Bolt M8*30 2

17 Top Plate 1 61 Philips Screw M5*12 9

18 Bushing 4 62 Hex Head Bolt M10*75 8

19 End Cap 4 63 Socket Head Cap Screw M4*15 2

20 Aluminium Cap 2 64 Socket Head Cap Screw M8*25 4

21 Linearity Bearing Φ30 4 65 Socket Head Cap Screw M10*15 2

22 Spring Ring 4 66 Flat Head Cap Screw M10*25 4

23 Hex Flanged Nut 2 67 Flat Head Cap Screw M10*40 2

24 Button 8 68 Hex Key S=3 1

25 Plastic Cover 1 69 Hex Key S=6 1

26 Cable 1 70 Hex Key S=8 1

28 Rear Shroud 1 71 Wrench 1

29 Support 1 72 Lube 1

30 Top Cover 1 74 Weight Plate 5LBS 2

39 Top Front Shroud 1 75 Weight Plate 10LBS 3

35 Adjustable Foot Plate 4 76 Weight Plate 15LBS 10

37 Plug RT50*100 2 77 Rivet Nut M5 5

40 Rubber Bumper 2 78 Rivet Nut M8 2

41 Foot Cover 4 82 Rubber PlugΦ29*Φ19*10 2

42 Plug RT40*80 2 84 Spring WasherΦ8 2

43 Left Plug 1 85 Flat Washer Φ9*Φ22*1.6 2

44 Right Plug 1
