─ 6 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

67 Hex Head Bolt M10*80 2 96 Lube 1

68 Hex Head Bolt M12*35 2 98 Spring Washer Φ8 2

70 Hex Head Bolt M12*80 2 110 Rear Shroud 1

71 Socket Head Cap Screw M4*15 1 111 Front Shroud 1

72 Socket Head Cap Screw M5*25 2 115 Baffle Plate 1

73 Socket Head Cap Screw M8*20 4 116 Hex Head Bolt M8*15 2

74 Socket Set Screw M8*8 4 130 Hex Head Bolt M10*75 2

75 Hex Head Bolt M8*30 2 131 Hex Head Bolt M10*55 1

77 Button Head Cap Screw M8*60 1 132 Hex Head Bolt M12*65 3

78 Socket Set Screw 10-32*3.2 4 133 Screw M5*12 9

79 Socket Set Screw 10-32*6.4 2 134 Rivet Nut M5 5

80 Flat Washer Φ13*Φ24*1.5 11 135 Shroud Clip 12

81 Flat Washer Φ9*Φ22*1.6 2 136 Plastic Cover 1

82 Flat Washer Φ5.5*Φ12*1 4 137 4.5" Pulley for Sensor 1

83 Flat Washer Φ11*Φ20*2 38 138 Plate for Sensor 1

84 Flat Washer Φ9*Φ16*1.6 8 139 Philips Screw M3*8 4

85 Nylon Lock Nut M10 13 140 Sensor 2

86 Nylon Lock Nut M12 4 141 Console PCB 1

87 Nylon Lock Nut M5 2 142 Cover for Magnetic Iron 1

88 Nylon Lock Nut M8 5 143 Magnetic Iron 4

89 Hex Nut M8 2 144 Screw ST2.9*9.5 2

90 Hex Key s=3 1 145 Top Front Shroud 1

91 Hex Key s=4 1 146 Front Support 1

92 Hex Key s=5 1 147 Top Cover 1

93 Hex Key s=6 1 148 Left Plug 1

94 Hex Key s=3/32" 1 149 Right Plug 1

95 Wrench 1 151 Hex Nut M10 2
