Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

1 Weight Stack Frame 1 37 Guide Rod Φ19*1177 2

2 Bottom Cross Brace 1 41 Bearing Φ50.8*Φ25.4*15.9 4

3 Main Frame 1 42 Flange 2

4 Seat Pad Support 1 44 Yellow Grip 1

5 Hand Bracket 1 45 Aluminium Grip Cap 2

6 Arm Bracket 1 47 Bumper Φ32*Φ25.4*40 1

7 Cam Wheel Brackets 1 48 Seat Pad 1

8 Top Cross Brace 1 49 Arm Pad 1

9 Main Bracket 1 50 Plastic Tube Guide 2

10 Adj. Handle 1 51 Spring 1

11 Pin 1 53 Big Aluminous Cap Φ60*Φ10.5*10 1

12 Main Shaft Φ25.4*335.4 1 54 Bushing 2

14 Scaleboard 1 57 Little Bumper Φ17*10.5 2

15 Adjustable Support 1 58 Bushing Φ16*8 2

16 Aluminium Cap Φ50*Φ10.5*8 2 59 Plate 2

17 Underlaying Flat Steel 1 65 Hex Head Bolt M12*35 4

18 Press Cable 1 66 Hex Head Bolt M10*55 1

19 Top Plate 1 67 Hex Head Bolt M10*135 2

20 Counter Poise Block 1 68 Hex Head Bolt M10*130 2

21 Rubber Plug Φ29*Φ19*10 2 69 Hex Head Bolt M10*100 2

24 Selector Pin W/Coil 1 70 Hex Head Bolt M10*80 2

26 Button Φ8*Φ20*23 12 71 Hex Head Bolt M10*50 2

27 Weight Rubber Bumper 2 72 Hex Head Bolt M10*35 2

28 Adjustable Foot plate 4 73 Hex Head Bolt M10*30 6

29 Grip Φ22*Φ30*145 2 74 Hex Head Bolt M10*25 2

34 4.5" Pulley 2 75 Flat Head Cap Screw M10*30 5

36 Plug RT50*100 1 76 Hex Head Bolt M10*20 2
