Aerofit IE9523 [6/24] 页面 6

Превью страниц Страница 6 / 24

─ 6 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

77 Socket Head Cap Screw M8*60 1 109 Socket Set Screw M8*8 4

78 Button Head Cap Screw M8*55 1 110 Nut 2

79 Socket Head Cap Screw M8*30 1 113 Rear Shroud 1

80 Socket Head Cap Screw M8*20 2 114 Front Shroud 1

81 Button Head Cap Screw M6*12 2 116 Hex Head Bolt M8*30 2

82 Hex Nut M6 2 117 Spring Washer Φ8 2

83 Socket Head Cap Screw M5*25 2 120 Rivet Nut M8 2

85 Socket Head Cap Screw M4*15 1 131 Socket Set Screw M6*15 2

86 Adjustable Support Sleeve 1 132 Hex Head Bolt M12*70 3

87 Weight Stack Space 2 133 Screw M5*12 9

89 Flat Washer Φ13*Φ24*1.5 11 134 Rivet Nut M5 5

90 Flat Washer Φ11*Φ20*2 36 135 Shroud clip 12

91 Flat Washer Φ9*Φ16*1.6 6 136 Plastic Cover 1

92 Flat Washer Φ5.5*Φ12*1 4 137 4.5" Pulley for Sensor 1

93 Nylon lock Nut M5 2 138 Plate for sensor 1

94 Nylon lock Nut M8 4 139 Philips Screw M3*8 4

95 Nylon lock Nut M10 13 140 Sensor 2

96 Nylon lock Nut M12 4 141 Console PCB 1

98 Hex Key s=3 1 142 Cover for Magnetic Iron 1

99 Hex Key s=4 1 143 Magnetic Iron 4

100 Hex Key s=5 1 144 Screw ST2.9*9.5 2

101 Hex Key s=6 1 145 Top Front Shroud 1

102 Flat Washer Φ9*Φ22*1.6 2 146 Front Support 1

104 Wrench 1 147 Top Cover 1

105 Lube 1 148 Left Plug 1

106 Location ring 1 149 Right Plug 1

107 Locking ring 1
