Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED

Item No.

Description Qty

Item No.

Description Qty

53 Rubber Sleeve Φ17*10.5 2 79 Socket Set Screw 10-32*3.2 4

54 Flat Washer Φ13*Φ24*1.5 2 80 Hex Key S=12 1

55 L Bracket 2 81 Hex Key S=3/32" 1

56 Flat Washer Φ11*Φ20*2 42 82 Hex Key S=4 1

57 Flat Washer Φ9*Φ16*1.6 2 83 Hex Key S=6 1

58 Hex Nut M16(L) 2 84 Hex Key S=8 1

59 Hex Nut M16 2 85 Wrench Φ6*117 1

60 Nylon Lock Nut M10 19 86 Lube 1

61 Nylon Lock Nut M12 1 90 Flat Head Cap Screw M10*25 6

62 Nylon Lock Nut M8 2 91 Top Rear Shroud-A 1

63 Flat Head Cap Screw M10*30 6 92 Shroud Retainer Plate 3

64 Hex Head Bolt M10*100 2 93 Right Shroud Retainer Plate 1

65 Hex Head Bolt M10*135 4 94 Front Shroud 1

66 Hex Head Bolt M10*20 2 95 Rear Shroud 1

67 Hex Head Bolt M10*45 1 96 Rear Support 1

68 Hex Head Bolt M10*50 6 97 Arc Bracket 1

69 Hex Head Bolt M10*80 2 98 Rivet Nut M8 2

70 Hex Head Bolt M12*100 1 99 Flat Philips Screw M5*25 2

71 Hex Head Bolt M10*25 4 100 Hex Head Bolt M8*30 2

72 Hex Head Bolt M10*30 4 101 Spring Washer Φ8 2

73 Socket Head Cap Screw M10*50 3 102 Flat Washer Φ9*Φ22*1.6 2

74 Socket Head Cap Screw M16*40 4 103 Connect Button Φ18*12 4

75 Socket Head Cap Screw M8*20 2 104 Plastic Cover Φ21*5.7 4

76 Socket Set Screw M8*8 2 105 Plastic Washer Φ13*3 4

77 Flat Philips Screw M5*16 17 106 Button Φ8.1*7 10

78 Self-Tapping Screw ST4.2*10 4
