22
Consumed Bottom Time (CBT)3.3.3.
The available no-decompression stop time is also shown visually in the multi-
function bar graph on the left side of the display (Fig. 3.7. and 3.8.). When your
available no-decompression time decreases below 200 minutes, the first (lowest)
bar graph segment appears. As your body absorbs more nitrogen, more segments
start to appear.
White Zone - As a safety precaution Suunto recommends you should maintain
the no-decompression bar graph within the green zone. Segments start to appear
when the available no-decompression time decreases below 100, 80, 60, 50, 40,
30 and 20 minutes.
Yellow Zone - As the bars reach the yellow zone, your no-decompression stop time
is less than 10 or 5 minutes and you are getting very close to no-decompression
limits. At this point, you should start your ascent towards the surface.
Red Zone - As all of the bars appear (red zone), your no-decompression stop time
has become zero and your dive has become a decompression stop dive (for more
information see section 3.3.5. “Decompression dives”).
Ascent Rate Indicator3.3.4.
The ascent rate is shown graphically along the right side of the display as fol-
lows:
TABLE 3.2. ASCENT RATE INDICATOR
Ascent Rate Indicator The equivalent ascent speed Example in Fig.
No segments Normal, full battery. 3.7
One segment 4 - 6 m/min [13 - 20 ft/min] 3.8
Two segments 6 - 8 m/min [20 - 26 ft/min] 3.9
Three segments 8 - 10 m/min [26 - 33 ft/min] 3.10
Four segments 10 - 12 m/min [33 - 39 ft/min] 3.11
Four segments,
the SLOW segment,
blinking depth
reading, the STOP
sign and an
audible alarm
Above 12 m/min [39 ft/min] or
continuously above 10 m/min
[33 ft/min]
3.12
