![Suunto Zoop [53/73] Caution](/views2/1013535/page53/bg35.png)
51
CAUTION!
When the battery is changed all nitrogen and oxygen uptake data is lost.
Therefore, the no-flying time shown by the computer should have reached
zero or you must wait for 48 hours or preferably even 100 hours between dives
before you may dive again.
All history and profile data, as well as the altitude, personal and alarm settings, will
remain in the dive computer memory after the battery change. However, the clock
time and time alarm setting is lost. In the NITROX Mode the Nitrox settings are also
reverted back to default settings (21 % O
2
, 1.4 bar PO
2
).
When working with the battery compartment, cleanliness is extremely important.
Even the smallest dirt particles may cause a leakage when you dive.
BATTERY KIT
The battery kit includes a 3.0 V coin type lithium cell battery and a lubricated O-ring.
When handling the battery do not make contact with both of the poles at the same
time. Do not touch the surfaces of the battery with your bare fingers.
TOOLS REQUIRED
• A at 1.5 mm screwdriver or a special tool for spring bars (K5857).
• Soft cloth for cleaning.
• Needlenose pliers or large screwdriver for turning securing ring.
BATTERY REPLACEMENT
The battery and the buzzer are located in the back of the instrument in a separate
compartment, the parts of which are shown in Fig. 5.1. To change the battery, follow
the procedure below:
1. Remove the computer from the console or boot.
Wrist model:
• Disassemble the shorter part of the strap with a at 1.5 mm screwdriver or a
special tool for spring bars. The longer part of the strap may stay on but remov-
ing it may ease the work later on.
Console model:
1. Remove the dive computer from the console according the instructions of the
console.
2. Thoroughly rinse and dry the computer.
3. Open the securing ring of the battery compartment lid by pushing it down and
rotating it clockwise. You may use a pointed nose pliers or a small screwdriver
as an aid in the rotating. Put the pliers ends into the holes of the securing ring or
