Suunto Zoop [19/73] Battery indication
![Suunto Zoop [19/73] Battery indication](/views2/1013535/page19/bg13.png)
17
Battery Indication3.1.2.
Battery Power Indicator3.1.2.1.
This dive computer has a unique graphic Battery Power Indicator designed to give
you an advance notice of impending need to change the battery.
The Battery Power Indicator can always be seen when the Dive Mode is activated.
The following Table and Figure show the various warning levels.
TABLE 3.1. BATTERY POWER INDICATOR
Temperature or an internal oxidation of the battery affects the battery voltage. If the
instrument is stored for a long period, the low battery warning may be displayed
even though the battery has enough capacity. The low battery warning may also
be displayed at low temperatures, even though the battery has enough capacity in
warmer conditions. In these cases repeat the battery check procedure.
After battery check the Low Battery Warning is indicated by the battery symbol
(Fig. 3.4.).
If the battery symbol is displayed in the Surface mode or if the display is faded
or weak, the battery may be too low to operate the dive computer and battery
replacement is recommended.
Display Operation Figure 3.2
BAT +
4 segments + OK
Normal, full battery. a
BAT +
3 segments
Normal, battery power is getting
low or the temperature is low.
Battery replacement is recommended
if you are going to colder conditions
or if you are planning to make a dive trip.
b
LOWBAT +
2 segments +
low battery symbol
Battery power is low and the battery
replacement is recommended.
The battery symbol is displayed.
c
LOWBAT +
1 segments + QUIT+
low battery symbol
Change the battery!
Returns to the Time display.
Activation and all functions are disabled.
d
