40
Page II (Fig. 4.7.)
• dive number in the dive series
• maximum depth
(NOTE! Due to lower resolution, the reading may differ from the
maximum depth reading of the Dive History up to 0.3 m [1 ft].)
• total dive time
• temperature at the maximum depth
• Altitude Adjustment setting
• Personal Adjustment setting
• SLOW label, if the diver has violated the maximum ascent rate
• STOP label, if the Mandatory Safety Stop was violated
• ASC TIME label, if the dive was a decompression stop dive
• Diver attention symbol, if the symbol was displayed when dive was started
v downward pointing arrow, if the ceiling was violated
v oxygen percentage
• maximum OLF during the dive (only in Nitrox mode).
Page III (Fig. 4.8.)
• dive number in the dive series
• average depth
• surface interval time before the dive
Page IV (Fig. 4.9.)
• dive number in the dive series
• the prole of the dive, automatic scrolling during which:
• logbook symbol blinks at the point when the user has pressed the PLAN
button for Bookmark
• O
2
% during the dive profile
• blinking SLOW label when registered
• blinking ASC TIME label when the dive became a decompression dive.
