AR-440
10
PARTS LIST
✽ New Parts. indicates safety critical components.
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
L : Scandinavia K : USA P : Canada
Y : PX (Far East, Hawaii) T : England E : Europe
Y : AAFES (Europe) X : Australia M :Other Areas
Ref. No.
Address
Parts No. Description
Desti-
nation
New
parts
Ref. No.
Address
Parts No. Description
Desti-
nation
New
parts
AR-440, DISPLAY UNIT (X54-3450-10)
TX-RX UNIT (X57-686X-XX)
11B✽ A01-2193-01 CABINET
23BA10-4048-21 CHASSIS
33A✽ A62-1102-03 PANEL ASSY
51D✽ B62-1745-10 INSTRUCTION MANUAL
63B✽ B72-2176-04 MODEL NAME PLATE C
63B✽ B72-2177-04 MODEL NAME PLATE C2
83BE04-0167-05 RF COAXIAL PECEPTACLE (M)
10 3C E30-2111-15 DC CORD ACCESSORY
13 3B ✽ E30-7512-05 DC CORD (RADIO)
14 3A E37-1082-05 SPEAKER WIRE
15 2A ✽ E37-1097-05 FLAT CABLE
18 2B F10-2449-01 SHIELDING COVER
19 2B,3C F51-0017-05 FUSE (6✽30) (15A)
23 2B G02-0894-04 EARTH SPRING (FINAL FET)
24 2A ✽ G10-1324-04 FIBROUS SHEET (DISPLAY UNIT)
25 3B G11-4127-14 RUBBER SHEET (CHASSIS)
26 2B G11-4240-04 RUBBER SHEET (DRIVE FET)
27 3B G13-1468-04 CUSHION (CHASSIS)
28 3A G53-1525-03 PACKING (PANEL)
29 2B G53-1542-03 PACKING (PHONE JACK)
30 1B G53-1544-01 PACKING (SHIELDING COVER)
31 1A G53-1548-02 GASKET
33 2C,1D H12-3112-05 PACKING FIXTURE
34 3D H13-1190-02 CARTON BOARD
36 1D H25-2341-04 PROTECTION BAG
37 2D ✽ H52-2030-02 ITEM CARTON CASE
39 3C J19-1584-05 MIC HOLDER ACCESSORY
40 3D J29-0662-03 BRACKET ACCESSORY
42 3A ✽ K29-9291-01 KEY TOP
43 3A ✽ K29-9292-03 KNOB (VOLUME)
44 3A ✽ K29-9293-03 KNOB (CNCODER)
A2BN67-2608-46 PAN HEAD SEMS SCREW W
B2AN80-2010-45 PAN HEAD TAPTITE SCREW
C 2B,3B N87-2606-46 BRAZIER HEAD TAPTITE SCREW
D 1B,2B N87-2614-46 BRAZIER HEAD TAPTITE SCREW
46 3D N99-0395-05 SCREW SET ACCESSORY
48 3A T07-0739-05 SPEAKER
50 2C ✽ T91-0641-05 MICROPHONE ACCESSORY
101 2A ✽ B11-1809-03 ILLUMINATION GUIDE (LCD)
102 2A ✽ B38-0885-05 LCD
D2-4 B30-2205-05 LED (YG)
D19-30 B30-2205-05 LED (YG)
C4 CC73GCH1H101J CHIP C 100PF J
C15,16 CC73GCH1H101J CHIP C 100PF J
C19 CK73GB1H681K CHIP C 680PF K
C22 CK73GB1H102K CHIP C 1000PF K
C24 CK73GB1C104K CHIP C 0.10UF K
C25 CK73GB1H102K CHIP C 1000PF K
C27 CK73GB1H102K CHIP C 1000PF K
C30 CK73GB1C104K CHIP C 0.10UF K
C31-33 CK73GB1H102K CHIP C 1000PF K
C34,35 CK73GB1H472K CHIP C 4700PF K
C36 CK73GB0J105K CHIP C 1.0UF K
C38 CK73GB1H471K CHIP C 470PF K
C39,40 CK73GB1C104K CHIP C 0.10UF K
103 2A ✽ E29-1201-04 INTER CONNECTOR (LCD)
CN1 E40-6005-05 FLAT CABLE CONNECTOR
J1 E08-0877-05 MODULAR JACK
104 2A ✽ J21-8463-03 HARDWARE FIXTURE (LCD)
L1 L92-0138-05 FERRITE CHIP
CP1 R90-0724-05 MULTI-COMP 1K X4
R8 RK73GB1J102J CHIP R 1.0K J 1/16W
R10 RK73GB1J122J CHIP R 1.2K J 1/16W
R21-23 RK73GB1J103J CHIP R 10K J 1/16W
R25 RK73GB1J563J CHIP R 56K J 1/16W
R26 RK73GB1J392J CHIP R 3.9K J 1/16W
R41 RK73FB2A560J CHIP R 56 J 1/10W
R42 RK73GB1J272J CHIP R 2.7K J 1/16W
R43 RK73GB1J821J CHIP R 820 J 1/16W
R44 RK73GB1J183J CHIP R 18K J 1/16W
R45 RK73GB1J333J CHIP R 33K J 1/16W
R46 RK73GB1J101J CHIP R 100 J 1/16W
R47,48 RK73GB1J473J CHIP R 47K J 1/16W
R49,50 RK73FB2A560J CHIP R 56 J 1/10W
R51-53 R92-1252-05 CHIP R 0 OHM J 1/16W
R55 R92-1252-05 CHIP R 0 OHM J 1/16W
R54 RK73FB2A560J CHIP R 56 J 1/10W
VR1 ✽ R31-0646-05 VARIABLE RESISTOR
D31 1SS355 DIODE
IC3 ✽ LC75854W MOS IC
IC3 ✽ PT6554LQ MOS IC
Q6 KRC102S DIGITAL TRANSISTOR
Q9 2SB1132(Q,R) TRANSISTOR
Q10 KRA225S DIGITAL TRANSISTOR
Q12 UMG3N TRANSISTOR
S1 ✽ W02-3665-05 ENCODER
C10 CK73GB1H102K CHIP C 1000PF K
C13-20 CK73GB1H471K CHIP C 470PF K
C28 CK73GB1H221K CHIP C 220PF K
C29 CK73GB1H471K CHIP C 470PF K
C30 CK73GB1H102K CHIP C 1000PF K
C32 CK73GB1H102K CHIP C 1000PF K
C33 CK73GB1H471K CHIP C 470PF K
C34 ✽ CE04EQ1E331M ELECTRO 330UF 25WV
C35-38 CK73GB1H471K CHIP C 470PF K
C39,40 CK73GB1C104K CHIP C 0.10UF K
AR-440
DISPLAY UNIT (X54-3450-10)
TX-RX UNIT (X57-686X-XX) 3-00 : C 3-01 : C2
