A
R-440
16
PARTS LIST
D606,607 MA742 DIODE
D608 1SS355 DIODE
IC31 KIA7808AF ANALOG IC
IC32,33 NJM78L05UA BI-POLAR IC
IC34 ✽ BD4732G MOS IC
IC35 BD4740G MOS IC
IC66 AT24C64A10SI18 ROM IC
IC66 ✽ CAT24WC64JI ROM IC
IC101 ✽ 30622MAA-B85GP MPU
IC161 M62363FP MOS IC
IC201 NJM2100V MOS IC
IC202 ✽ BA10358FV MOS IC
IC203 ✽ BA10324AFV MOS IC
IC204,205 BU4S66 MOS IC
IC251 ✽ BA10324AFV MOS IC
IC252 2B LA4600 BI-POLAR IC
IC301 TK14489V BI-POLAR IC
IC401 MB15A02 MOS IC
IC501 TA75W01FU MOS IC
Q31 2SA1641(S,T) TRANSISTOR
Q32 KRC102S DIGITAL TRANSISTOR
Q33 2SA1745(6,7) TRANSISTOR
Q34 KRC102S DIGITAL TRANSISTOR
Q35 KTA1664(Y) TRANSISTOR
Q36 KRC102S DIGITAL TRANSISTOR
Q61 KRC404RTK DIGITAL TRANSISTOR
Q86,87 2SK1830 FET
Q201 2SC4919 TRANSISTOR
Q251 2SC2412K TRANSISTOR
Q252,253 2SK3019 FET
Q254 DTC363EU DIGITAL TRANSISTOR
Q255 KRC102S DIGITAL TRANSISTOR
Q301,302 2SC2412K TRANSISTOR
Q351 2SC5108(Y) TRANSISTOR
Q352,353 3SK255 FET
Q354 2SK1830 FET C2
Q402 2SA1832(GR) TRANSISTOR
Q403 2SC4738(GR) TRANSISTOR
Q404 2SC4649(N,P) TRANSISTOR
Q405,406 2SK508NV(K52) FET
Q407 2SJ347 FET
Q408 KRX102U TRANSISTOR
Q410,411 2SC5108(Y) TRANSISTOR
Q440 2SC2412K TRANSISTOR
Q500 2SC5110(O) TRANSISTOR
Q501 2SC3356(R24) TRANSISTOR
Q502 2SK2596 FET
Q503 PD55008TR DRIVE FET
Q504 2B RD60HUF1-01 FINAL FET
TH97,98 ✽ NCP18WF104J03 THERMISTOR
TH301 ✽ NCP18WF104J03 THERMISTOR
TH351 NCP18XW332J03 THERMISTOR
TH352 ✽ NCP18XQ102J03 THERMISTOR
TH401 NCP18XH103K03 THERMISTOR C2
Ref. No.
Address
Parts No. Description
Desti-
nation
New
parts
Ref. No.
Address
Parts No. Description
Desti-
nation
New
parts
TX-RX UNIT (X57-686X-XX)
