PARTS LIST
Ref. No.
Address
Parts No. Description
Desti-
nation
New
parts
Ref. No.
Address
Parts No. Description
Desti-
nation
New
parts
TX-RX UNIT (X57-686X-XX)
R87 RK73GB1J102J CHIP R 1.0K J 1/16W
R91,92 RK73GB1J102J CHIP R 1.0K J 1/16W
R93 RK73GB1J682J CHIP R 6.8K J 1/16W C
R93,94 RK73GB1J822J CHIP R 8.2K J 1/16W C2
R94 RK73GB1J822J CHIP R 8.2K J 1/16W C
R101,102 RK73GB1J473J CHIP R 47K J 1/16W
R103-106 RK73GB1J102J CHIP R 1.0K J 1/16W
R109 RK73GB1J152J CHIP R 1.5K J 1/16W
R110 RK73GB1J473J CHIP R 47K J 1/16W
R111 RK73GB1J102J CHIP R 1.0K J 1/16W
R114 RK73GB1J473J CHIP R 47K J 1/16W
R118 R92-1252-05 CHIP R 0 OHM J 1/16W
R119 R92-0670-05 CHIP R 0 OHM C
R123 R92-1252-05 CHIP R 0 OHM J 1/16W
R124-127 RK73GB1J473J CHIP R 47K J 1/16W
R151 RK73GB1J103J CHIP R 10K J 1/16W
R152 RK73GB1J472J CHIP R 4.7K J 1/16W
R161 RK73GB1J122J CHIP R 1.2K J 1/16W
R162 RK73GB1J152J CHIP R 1.5K J 1/16W
R164-166 RK73GB1J102J CHIP R 1.0K J 1/16W
R200 RK73GB1J681J CHIP R 680 J 1/16W
R203 RK73GB1J104J CHIP R 100K J 1/16W
R204 RK73GB1J183J CHIP R 18K J 1/16W
R205 RK73GB1J821J CHIP R 820 J 1/16W
R206 RK73GB1J101J CHIP R 100 J 1/16W
R207 RK73GB1J754J CHIP R 750K J 1/16W
R208 RK73GB1J152J CHIP R 1.5K J 1/16W
R209 RK73GB1J244J CHIP R 240K J 1/16W
R210 RK73GB1J183J CHIP R 18K J 1/16W
R211,212 RK73GB1J823J CHIP R 82K J 1/16W
R213 RK73GB1J334J CHIP R 330K J 1/16W
R214,215 RK73GB1J683J CHIP R 68K J 1/16W
R216 RK73GB1J274J CHIP R 270K J 1/16W
R217 RK73GB1J224J CHIP R 220K J 1/16W
R218 RK73GB1J823J CHIP R 82K J 1/16W
R219 RK73GB1J393J CHIP R 39K J 1/16W
R220,221 RK73GH1J153D CHIP R 15K D 1/16W
R222 RK73GB1J103J CHIP R 10K J 1/16W
R224 RK73GB1J561J CHIP R 560 J 1/16W
R225 RK73GB1J154J CHIP R 150K J 1/16W
R226 RK73GB1J104J CHIP R 100K J 1/16W
R227 RK73GB1J223J CHIP R 22K J 1/16W
R228 RK73GB1J103J CHIP R 10K J 1/16W
R229 RK73GB1J684J CHIP R 680K J 1/16W
R230 RK73GB1J224J CHIP R 220K J 1/16W
R231 RK73GB1J124J CHIP R 120K J 1/16W
R232 RK73GB1J912J CHIP R 9.1K J 1/16W
R233 RK73GB1J682J CHIP R 6.8K J 1/16W
R234 R92-1252-05 CHIP R 0 OHM J 1/16W
R236 RK73GB1J103J CHIP R 10K J 1/16W
R237 R92-1252-05 CHIP R 0 OHM J 1/16W
R246 RK73GB1J154J CHIP R 150K J 1/16W
R247 RK73GB1J124J CHIP R 120K J 1/16W
R248 RK73GB1J562J CHIP R 5.6K J 1/16W
R249 RK73GB1J153J CHIP R 15K J 1/16W
R250 RK73GB1J123J CHIP R 12K J 1/16W
R251 RK73GB1J473J CHIP R 47K J 1/16W
R252 RK73GB1J474J CHIP R 470K J 1/16W
R253 R92-1252-05 CHIP R 0 OHM J 1/16W
R254 RK73GB1J272J CHIP R 2.7K J 1/16W
R255,256 RK73GB1J562J CHIP R 5.6K J 1/16W
R257 RK73GB1J105J CHIP R 1.0M J 1/16W
R258 RK73GB1J272J CHIP R 2.7K J 1/16W
R259 RK73GB1J123J CHIP R 12K J 1/16W
R260 RK73GB1J224J CHIP R 220K J 1/16W
R261 RK73GB1J124J CHIP R 120K J 1/16W
R262 RK73GB1J183J CHIP R 18K J 1/16W
R263 RK73GH1J913D CHIP R 91K D 1/16W
R264 RK73GH1J124D CHIP R 120K D 1/16W
R265 RK73GH1J562D CHIP R 5.6K D 1/16W
R266 RK73GB1J562J CHIP R 5.6K J 1/16W
R268 RK73GB1J102J CHIP R 1.0K J 1/16W
R269 RK73GB1J393J CHIP R 39K J 1/16W
R271 RK73GB1J332J CHIP R 3.3K J 1/16W
R272 RK73GB1J392J CHIP R 3.9K J 1/16W
R273 RK73GB1J123J CHIP R 12K J 1/16W
R274,275 RK73GB1J153J CHIP R 15K J 1/16W
R276 RK73GB1J473J CHIP R 47K J 1/16W
R277 RK73GB1J683J CHIP R 68K J 1/16W
R278 RK73GB1J123J CHIP R 12K J 1/16W
R279 RK73GB1J472J CHIP R 4.7K J 1/16W
R280 RK73GB1J391J CHIP R 390 J 1/16W
R281 R92-0670-05 CHIP R 0 OHM
R301,302 RK73GB1J472J CHIP R 4.7K J 1/16W
R303 RK73GB1J223J CHIP R 22K J 1/16W
R304 RK73GB1J472J CHIP R 4.7K J 1/16W
R305 RK73GB1J182J CHIP R 1.8K J 1/16W
R306 RK73GB1J274J CHIP R 270K J 1/16W
R308 RK73GB1J334J CHIP R 330K J 1/16W
R309 RK73GB1J332J CHIP R 3.3K J 1/16W
R310 RK73GB1J102J CHIP R 1.0K J 1/16W
R311 RK73GB1J333J CHIP R 33K J 1/16W
R312 RK73GB1J473J CHIP R 47K J 1/16W
R313 RK73GB1J104J CHIP R 100K J 1/16W
R314 RK73GB1J222J CHIP R 2.2K J 1/16W
R315 RK73GB1J183J CHIP R 18K J 1/16W
R316 RK73GB1J223J CHIP R 22K J 1/16W
R317-320 RK73GB1J103J CHIP R 10K J 1/16W
R321 RK73GB1J223J CHIP R 22K J 1/16W
R322 RK73GB1J101J CHIP R 100 J 1/16W
R323 RK73GB1J124J CHIP R 120K J 1/16W
R324 R92-1252-05 CHIP R 0 OHM J 1/16W
R325 RK73GB1J333J CHIP R 33K J 1/16W
R349 RK73GB1J473J CHIP R 47K J 1/16W C2
R350 RK73GB1J273J CHIP R 27K J 1/16W C1
R351 RK73GB1J471J CHIP R 470 J 1/16W
R352 RK73GB1J101J CHIP R 100 J 1/16W
R353 RK73GB1J104J CHIP R 100K J 1/16W
R354 RK73GB1J561J CHIP R 560 J 1/16W
R355 RK73GB1J681J CHIP R 680 J 1/16W
R358 RK73GB1J390J CHIP R 39 J 1/16W C2
R358 RK73GB1J470J CHIP R 47 J 1/16W C
R359 RK73GB1J823J CHIP R 82K J 1/16W
R360 RK73GB1J474J CHIP R 470K J 1/16W
R361 RK73GB1J270J CHIP R 27 J 1/16W
R362 RK73GB1J474J CHIP R 470K J 1/16W
R363 RK73GB1J224J CHIP R 220K J 1/16W
R364 R92-1252-05 CHIP R 0 OHM J 1/16W
R365,366 RK73GB1J104J CHIP R 100K J 1/16W
R367 RK73GB1J101J CHIP R 100 J 1/16W
