![Ajetrays AR-440 [11/46] Ar 440](/img/pdf.png)
Ajetrays AR-440 [11/46] Ar 440
![Ajetrays AR-440 [11/46] Ar 440](/views2/1141997/page11/bgb.png)
A
R-440
11
PARTS LIST
Ref. No.
Address
Parts No. Description
Desti-
nation
New
parts
Ref. No.
Address
Parts No. Description
Desti-
nation
New
parts
TX-RX UNIT (X57-686X-XX)
C41 C92-0795-05 CHIP-TAN 22UF 10WV
C42 CK73GB1H103K CHIP C 0.010UF K
C43-45 C92-0795-05 CHIP-TAN 22UF 10WV
C48-50 CK73GB1H103K CHIP C 0.010UF K
C51 C92-0589-05 CHIP-TAN 47UF 6.3WV
C52,53 CK73GB1H471K CHIP C 470PF K
C54,55 CK73GB1C104K CHIP C 0.10UF K
C56 CK73GB1H471K CHIP C 470PF K
C61 CK73GB1H471K CHIP C 470PF K
C66 CK73GB1H471K CHIP C 470PF K
C82 CK73GB1H471K CHIP C 470PF K
C83 CK73GB1C104K CHIP C 0.10UF K
C87 CC73GCH1H030C CHIP C 3.0PF C
C88,89 CC73GCH1H040C CHIP C 4.0PF C
C90 CC73GCH1H030C CHIP C 3.0PF C
C97,98 CK73GB1H471K CHIP C 470PF K
C101 CK73GB1H471K CHIP C 470PF K
C102 CK73GB1C104K CHIP C 0.10UF K
C104 CK73GB1C104K CHIP C 0.10UF K
C128 CK73GB1H102K CHIP C 1000PF K
C151 CK73GB1H182K CHIP C 1800PF K
C152 CK73GB1H392K CHIP C 3900PF K
C161 CK73GB1H102K CHIP C 1000PF K
C162 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C163 CK73GB1H471K CHIP C 470PF K
C164 C92-0560-05 CHIP-TAN 10UF 6.3WV
C165 CK73GB1A105K CHIP C 1.0UF K
C201 CK73GB1C104K CHIP C 0.10UF K
C202 CK73GB1H471K CHIP C 470PF K
C203 CK73GB1C273K CHIP C 0.027UF K
C204 C92-0514-05 CHIP-TAN 2.2UF 10WV
C205 CK73GB1C104K CHIP C 0.10UF K
C206 CK73GB1H102K CHIP C 1000PF K
C207 CK73GB1C223K CHIP C 0.022UF K
C208 CK73GB1H103K CHIP C 0.010UF K
C209 CC73GCH1H680J CHIP C 68PF J
C210 CK73GB1C104K CHIP C 0.10UF K
C211 CK73GB1H821K CHIP C 820PF K
C212 CK73GB1H122K CHIP C 1200PF K
C213 CK73GB1H332K CHIP C 3300PF K
C214 CC73GCH1H151J CHIP C 150PF J
C215 CK73GB1C104K CHIP C 0.10UF K
C216 CC73GCH1H390J CHIP C 39PF J
C217,218 C92-0560-05 CHIP-TAN 10UF 6.3WV
C220 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C222 CK73GB1C104K CHIP C 0.10UF K
C225 C92-0004-05 CHIP-TAN 1.0UF 16WV
C226 CK73GB1H472K CHIP C 4700PF K
C227 CK73GB1E103K CHIP C 0.010UF K
C228 C92-0560-05 CHIP-TAN 10UF 6.3WV
C230 CK73GB1C104K CHIP C 0.10UF K
C231,232 CK73GB1H471K CHIP C 470PF K
C233 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C235 CK73GB1A105K CHIP C 1.0UF K
C249 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C250 CK73GB1C104K CHIP C 0.10UF K
C251 C92-0714-05 CHIP-TAN 4.7UF 6.3WV
C252 CC73GCH1H390J CHIP C 39PF J
C253,254 CK73GB1A224K CHIP C 0.22UF K
C255 CK73GB1H822K CHIP C 8200PF K
C256 CK73GB1E183K CHIP C 0.018UF K
C257 CK73GB1C393K CHIP C 0.039UF K
C258-261 CK73GB1H103J CHIP C 0.010UF J
C262 CK73GB1H471K CHIP C 470PF K
C263,264 CK73GB1C333K CHIP C 0.033UF K
C265 CK73GB1C104K CHIP C 0.10UF K
C266 CK73GB1A105K CHIP C 1.0UF K
C267 CK73GB1A474K CHIP C 0.47UF K
C268 CK73GB1A105K CHIP C 1.0UF K
C270 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C271 CK73GB1H122K CHIP C 1200PF K
C272 CK73GB1H102K CHIP C 1000PF K
C273 CK73GB1A105K CHIP C 1.0UF K
C274 CK73FB1C224K CHIP C 0.22UF K
C275 CK73GB1A105K CHIP C 1.0UF K
C276,277 CK73GB1H471K CHIP C 470PF K
C278 CK73GB1C104K CHIP C 0.10UF K
C279 C92-0516-05 CHIP-TAN 4.7UF 16WV
C280 C92-0040-05 CHIP-ELE 47UF 16WV
C281 CK73GB1H471K CHIP C 470PF K
C282 ✽ CE04EQ1E331M ELECTRO 330UF 25WV
C283 CK73GB1H102K CHIP C 1000PF K
C301 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C302 CK73GB1H102K CHIP C 1000PF K
C303 CK73GB1H472K CHIP C 4700PF K
C304,305 CC73GCH1H221J CHIP C 220PF J
C306 CK73GB1H102K CHIP C 1000PF K
C307 CK73GB1E223K CHIP C 0.022UF K
C308 CK73GB1H102K CHIP C 1000PF K
C309 CK73GB1E223K CHIP C 0.022UF K
C310 CK73FB1C334K CHIP C 0.33UF K
C311,312 CK73GB1C104K CHIP C 0.10UF K
C313 C92-0662-05 CHIP-TAN 15UF 6.3WV
C314 CK73GB1H103K CHIP C 0.010UF K
C315-318 CK73GB1C104K CHIP C 0.10UF K
C319 CK73GB1H102K CHIP C 1000PF K
C321 CC73GCH1H680J CHIP C 68PF J
C322 CC73GCH1H560J CHIP C 56PF J
C323 CC73GCH1H271J CHIP C 270PF J
C324 CK73GB1H103K CHIP C 0.010UF K
C326 CK73GB1H103K CHIP C 0.010UF K
C350 CK73GB1H471K CHIP C 470PF K C2
C351 CC73GCH1H330J CHIP C 33PF J
C353 CK73GB1H103K CHIP C 0.010UF K
C354 CC73GCH1H060B CHIP C 6.0PF B
C355 CC73GCH1H180J CHIP C 18PF J
C356 CC73GCH1H020B CHIP C 2.0PF B
C357 CK73GB1H103K CHIP C 0.010UF K
C358 CK73GB1H471K CHIP C 470PF K
C359 CC73GCH1H120J CHIP C 12PF J
C360 CC73GCH1H080B CHIP C 8.0PF B
C361,362 CK73GB1H471K CHIP C 470PF K
C363 CK73GB1H103K CHIP C 0.010UF K
C364 CK73GB1H471K CHIP C 470PF K
C366 CK73GB1C104K CHIP C 0.10UF K
C367 CK73GB1H471K CHIP C 470PF K
C368 CC73GCH1H070B CHIP C 7.0PF B C
C368 CC73GCH1H100C CHIP C 10PF C C2
C369 CC73GCH1HR75B CHIP C 0.75PF B C2
C370 CK73GB1H471K CHIP C 470PF K
