A
R-440
13
PARTS LIST
Ref. No.
Address
Parts No. Description
Desti-
nation
New
parts
Ref. No.
Address
Parts No. Description
Desti-
nation
New
parts
TX-RX UNIT (X57-686X-XX)
C555 CK73FB1C474K CHIP C 0.47UF K
C556 C93-0599-05 CHIP C 470PF K
C559 CK73GB1H103K CHIP C 0.010UF K
C560 CK73GB1H471K CHIP C 470PF K
C564 CM73F2H150J CHIP C 15PF J C2
C564 CM73F2H200J CHIP C 20PF J C
C567 CM73F2H100D CHIP C 10PF D C
C570 C93-0599-05 CHIP C 470PF K
C571 CK73GB1H471K CHIP C 470PF K
C572,573 CK73GB1H103K CHIP C 0.010UF K
C574 CK73GB1H102K CHIP C 1000PF K
C575 CK73GB1H471K CHIP C 470PF K
C576 CK73GB1H221K CHIP C 220PF K
C579 CM73F2H090D CHIP C 9.0PF D C2
C580 C93-0554-05 CHIP C 4.0PF C C2
C601 CC73GCH1H050B CHIP C 5.0PF B C
C602 C93-0560-05 CHIP C 10PF D C
C602 C93-0599-05 CHIP C 470PF K C2
C603 CC73GCH1H0R5B CHIP C 0.5PF B
C604 CC73GCH1H010B CHIP C 1.0PF B C2
C604 CC73GCH1H020B CHIP C 2.0PF B C
C605 C93-0554-05 CHIP C 4.0PF C C2
C605 C93-0556-05 CHIP C 6.0PF D C
C607 CC73GCH1H0R5B CHIP C 0.5PF B
C608 CC73GCH1H020B CHIP C 2.0PF B C
C608 CC73GCH1H030B CHIP C 3.0PF B C2
C610 C93-0556-05 CHIP C 6.0PF D C2
C610 C93-0560-05 CHIP C 10PF D C
C611 C93-0553-05 CHIP C 3.0PF C C
C611 C93-0554-05 CHIP C 4.0PF C C2
C613,614 CK73GB1H471K CHIP C 470PF K
C620 C93-0550-05 CHIP C 1.0PF C C2
TC401 C05-0245-05 CERAMIC TRIMMER CAP (10PF) C
TC401,402 C05-0245-05 CERAMIC TRIMMER CAP (10PF) C2
TC402 C05-0399-05 CERAMIC TRIMMER CAP (6PF) C
- E11-0425-05 3.5D PHONE JACK (3P)
- E37-1127-05 PROCESSED LEAD WIRE
CN1 E40-6268-05 FLAT CABLE CONNECTOR
CN2 E40-5705-05 PIN ASSY
CN5 E40-3246-05 PIN ASSY
F1 F53-0246-05 FUSE(4.0A/32V)
F501 F53-0108-05 FUSE(1.8A/50V)
CF301 L72-0993-05 CERAMIC FILTER
CF302 L72-0999-05 CERAMIC FILTER
L101 L92-0443-05 FERRITE CHIP
L201 L92-0443-05 FERRITE CHIP
L301 L34-4554-05 COIL
L302 L41-3385-08 SMALL FIXED INDUCTOR
L303,304 L40-3381-86 SMALL FIXED INDUCTOR (0.33UH)
L351,352 L40-4785-85 SMALL FIXED INDUCTOR (0.47UH)
L354,355 L34-4604-05 AIR-CORE COIL C2
L354,355 L34-4605-05 AIR-CORE COIL C
L356 L40-1875-92 SMALL FIXED INDUCTOR (18NH) C2
L356 L40-2275-92 SMALL FIXED INDUCTOR (22NH) C
L357 L40-3375-92 SMALL FIXED INDUCTOR (33NH) C2
L357 L40-3975-92 SMALL FIXED INDUCTOR (39NH) C
L358 L34-4605-05 AIR-CORE COIL C2
L358,359 L34-4605-05 AIR-CORE COIL C
L359 L34-4604-05 AIR-CORE COIL C2
L360 L34-4603-05 AIR-CORE COIL C2
L360,361 L34-4604-05 AIR-CORE COIL C
L361 L34-4604-05 AIR-CORE COIL C2
L401 L92-0443-05 FERRITE CHIP
L403 L41-1005-08 SMALL FIXED INDUCTOR
L404 L92-0442-05 FERRITE CHIP
L405 L92-0443-05 FERRITE CHIP
L406,407 L40-2785-92 SMALL FIXED INDUCTOR (270NH) C
L406,407 L40-4791-86 SMALL FIXED INDUCTOR (4.7UH) C2
L408 L40-2778-67 SMALL FIXED INDUCTOR (27NH) C2
L408 L40-5678-67 SMALL FIXED INDUCTOR (56NH) C
L409-412 L40-2785-92 SMALL FIXED INDUCTOR (270NH) C
L409,410 L40-4791-86 SMALL FIXED INDUCTOR (4.7UH) C2
L411,412 L40-2702-86 SMALL FIXED INDUCTOR (27UH) C2
L413 L40-2778-67 SMALL FIXED INDUCTOR (27NH) C2
L413 L40-4778-67 SMALL FIXED INDUCTOR (47NH/8) C
L414 L40-1885-92 SMALL FIXED INDUCTOR (180NH) C
L414,415 L40-2702-86 SMALL FIXED INDUCTOR (27UH) C2
L415 L40-2785-92 SMALL FIXED INDUCTOR (270NH) C
L416,417 L92-0443-05 FERRITE CHIP
L418 L41-2775-06 SMALL FIXED INDUCTOR
L420 L41-2775-06 SMALL FIXED INDUCTOR
L470 L40-2275-92 SMALL FIXED INDUCTOR (22NH) C2
L470 L40-2775-92 SMALL FIXED INDUCTOR (27NH) C
L501 L41-1575-06 SMALL FIXED INDUCTOR
L502 L41-2275-08 SMALL FIXED INDUCTOR
L503 L41-3363-08 SMALL FIXED INDUCTOR
L504 L41-1075-08 SMALL FIXED INDUCTOR
L505 L34-4603-05 AIR-CORE COIL
L506 L34-4607-05 AIR-CORE COIL
L507 L34-4602-05 AIR-CORE COIL C2
L507 L34-4603-05 AIR-CORE COIL C
L508 L34-4694-05 AIR-CORE COIL
L509 L34-4667-05 AIR-CORE COIL
L601 L34-4669-05 AIR-CORE COIL
L602,603 L34-4694-05 AIR-CORE COIL
L604 L34-4667-05 AIR-CORE COIL
X86 ✽ L78-1409-05 RESONATOR (8.00MHZ)
X401 ✽ L77-1944-05 TCXO (16.8MHZ)
XF351 ✽ L71-0620-05 MCF (49.95MHZ)
R1 R92-1252-05 CHIP R 0 OHM J 1/16W
R2,3 RK73GB1J101J CHIP R 100 J 1/16W
R4-8 RK73GB1J102J CHIP R 1.0K J 1/16W
R31 RK73GB1J472J CHIP R 4.7K J 1/16W
R32 R92-1215-05 CHIP R 470 J 1/2W
R33 RK73GB1J473J CHIP R 47K J 1/16W
R34 RK73GB1J472J CHIP R 4.7K J 1/16W
R35 RK73GB1J473J CHIP R 47K J 1/16W
R36 RK73GB1J152J CHIP R 1.5K J 1/16W
R37 RK73GB1J103J CHIP R 10K J 1/16W
R38 RK73GB1J334J CHIP R 330K J 1/16W
R39 RK73GB1J474J CHIP R 470K J 1/16W
R40 RK73GB1J394J CHIP R 390K J 1/16W
R41 RK73GB1J334J CHIP R 330K J 1/16W
R61 RK73GB1J471J CHIP R 470 J 1/16W
R62,63 R92-1252-05 CHIP R 0 OHM J 1/16W
R70 RK73GB1J473J CHIP R 47K J 1/16W
R81 RK73GB1J473J CHIP R 47K J 1/16W
R82 R92-1252-05 CHIP R 0 OHM J 1/16W
R86 R92-1252-05 CHIP R 0 OHM J 1/16W
