Philips FC8913 [8/140] Tri active nozzle specific types only

- Telescopic tube with button connection (specic types only): Press the spring-loaded lock

button and pull the handgrip out of the tube.

3 Adjust the telescopic tube to the length you nd most comfortable during vacuuming. (Fig. 6)

Hold the collar with one hand and pull the tube part above the collar upwards or push it

downwards with the other hand.



1 To connect the tube to one of the accessories: (Fig. 7)

- Telescopic tube with conical connection (specic types only): Insert the telescopic tube into the

accessory while turning it a little.

- Telescopic tube with button connection (specic types only): Press the spring-loaded lock

button on the telescopic tube and insert the tube into the accessory. Fit the spring-loaded lock

button into the opening in the accessory (‘click’).

2 To disconnect the telescopic tube from one of the accessories:

- Telescopic tube with conical connection (specic types only): Pull the telescopic tube out of the

accessory while turning it a little.

- Telescopic tube with button connection (specic types only): Press the spring-loaded lock

button and pull the tube out of the accessory.

Tip: The small nozzle, crevice tool and small brush (specic types only) can also be connected to the

handgrip of the hose.



1 Insert the crevice tool and the small nozzle into the clip.

2 Snap the accessory clip onto the tube (Fig. 8).

3 Pull the accessory clip from the tube to remove it.



The Tri-Active nozzle is a multi-purpose nozzle for carpets and hard oors.

- The side brushes catch more dust and dirt at the sides of the nozzle and allow you to clean

better along furniture and other obstacles (Fig. 9).

- The opening at the front of the nozzle allows you to suck up larger particles (Fig. 10).

1 Use the hard oor setting to clean hard oors (for instance tiled, parqueted, laminated and

linoleumed ooring): push the rocker switch on top of the nozzle with your foot to make the

brush strip come out of the housing. At the same time, the wheel is lifted to prevent

scratching and to increase manoeuvrability (Fig. 11).

2 Use the carpet setting to clean carpets: push the rocker switch again to make the brush strip

disappear into the nozzle housing. The wheel is lowered automatically (Fig. 12).



The combination nozzle can be used on either carpets or hard oors.

1 To clean hard oors, push the rocker switch on top of the nozzle with your foot (Fig. 13).

, The brush strip for cleaning hard oors comes out of the nozzle housing.

2 To clean carpets, push the rocker switch again (Fig. 14).

, The brush strip disappears into the nozzle housing.



- The hard-oor nozzle is designed for gentle cleaning of hard oors (Fig. 15).

8
