Philips Avent SCD 535 [10/292] Using the appliance

Note: When the parent unit is not in the charger, the battery pack gradually discharges, even when the

parent unit is switched off.

using the appliance

1 Place the parent unit and the baby unit in the same room to test the connection (Fig. 10).

Make sure the baby unit is at least 1 metre/3 feet away from the parent unit.

2 Press and hold the on/off button 3on the baby unit until the green power-on light goes

on. (Fig. 11)

Note: The power-on light always lights up green, even when there is no connection with the parent unit.

, The nightlight lights up briey and then fades out again.

, The display lights up and the battery symbol appears on the display (Fig. 12).

, After 2 seconds the temperature and humidity values are shown on the display (Fig. 13).

3 Press and hold the on/off button 3on the parent unit until the sound level lights light up

briey. (Fig. 14)

, The display goes on and the battery symbol appears on the display (Fig. 15).

, The LINK light ashes red and the message ‘Searching’ appears on the display (Fig. 16).

, The LINK light on the parent unit turns green and lights up continuously when a connection

has been established between the baby unit and parent unit. The message ‘Linked’ appears on

the display (Fig. 17).

, After 2 seconds the message ‘Linked’ disappears and the temperature and humidity values

are shown on the display. (Fig. 18)

, The rst time you switch on the parent unit, the message ‘Language’ appears on the display.

Select the desired language (see chapter ‘Menu options, section ‘Setting display

language’) (Fig. 19).

, If no connection is established, the LINK light on the parent unit ashes red. The parent

unit beeps from time to time and the message ‘Searching’ appears on the display, followed by

the message ‘Not Linked’ (Fig. 20).

Positioning the baby monitor

1 Place the baby unit at least 1 metre/3 feet away from your baby (Fig. 21).

2 Place the parent unit within the operating range of the baby unit. Make sure it is at least 1

metre/3 feet away from the baby unit to avoid acoustic feedback (Fig. 10).

For more information on the operating range, see section ‘Operating range’ below.

Operating range

The operating range of the baby monitor is 330 metres/1000 feet in open air. Depending on the

surroundings and other factors that may cause interference, this range may be smaller. Indoors the

operating range is up to 50 metres/150 feet.

Note: If the ECO mode is switched on, the operating range of the baby monitor is also smaller. See

section ‘ECO mode’ in chapter ‘Menu options’.

Dry materials Material thickness Loss of range

Wood, plaster, cardboard, glass

(without metal, wires or lead)

< 30cm/12in 0-10%

Brick, plywood < 30cm/12in 5-35%

Reinforced concrete < 30cm/12in 30-100%

Metal grilles or bars < 1cm /0.4in 90-100%

ENGLISH10
