10
VM-8HN - Connecting the VM-8HN
5.2 Setting the DIP-Switches
The eight DIP-switches located on the back panel are used for video wall, 5V DC,
MAC settings and force RGB.
The DIP-switch status is sampled when the device is reset. The unit must be
powered off and on for the new settings to activate.
DIPs 1&2 - Video Wall Delay
DIP 1
DIP 2
Video Wall Delay
up
up
Video wall off –
0 delay
down
up
On – 10 sec delay
up
down
On – 15 sec delay
down
down
On – 17 sec delay
DIPs 3&4 - Output 5V Off Delay
DIP 3
DIP 4
Output 5V Off Delay
up
up
15 mins
up
down
1 min
down
up
15 sec
down
down
5 sec
DIP 5 – MAC Mode
DIP 5
MAC Mode
up
MAC on
down
MAC off
Note: MAC mode does not support HDCP.
DIP 6 – Force RGB
DIP 6
Force RGB
up
Use monitor EDID
down
Use monitor EDID and force
RGB support
Note: After setting force RGB, you must reset the device.
DIPs 7 – Reserved for future use
DIP 8 – Firmware Update
DIP 8
FW Update
up
Normal operation
down
Update firmware
