VM-8HN - Protocol 3000
15
6.3 EDID Source
Number
Value
0
Input
1
Output
2
Default EDID
6.4 Signal Validation
Number
Value
0
Signal or sink is not valid
1
Signal or sink is valid
2
Sink and EDID is valid
6.5 Stage
Number
Value
0
Input
1
Output
2
(Reserved)
3
(Reserved)
6.6 HDCP Types
Number
Value
0
HDCP Off
1
HDCP On
2
Follow input
3
Mirror output (“MAC mode”)
