VM-8HN - Protocol 3000
11
6 Protocol 3000
6.1 Command Summary
The VM-8HN supports the following Protocol 3000 commands:
Command
Description
Type
Permission
CPEDID
Copy EDID data from the output to the input
EEPROM
EDID Handling
End User
DISPLAY?
Get output HPD status
System
End User
FACTORY
Reset device to factory default configuration
System-mandatory
End User
HDCP-STAT?
Get HDCP signal status
System
End User
RESET
Reset device
System-mandatory
End User
SIGNAL?
Get input signal lock status
System
End User
SN?
Get device serial number
System-mandatory
End User
6.2 Command Details
Command - CPEDID
Command Type - EDID Handling
Command Name
Transparency
Set:
CPEDID
Public
Get:
-
-
Description
Syntax
Set:
Copy EDID data from the output to
the input EEPROM
#CPEDID␠src_type, src_id, dst_type,
dest_bitmap␍
Get:
-
-
Response
~nn@CPEDID␠src_stg, src_id, dst_type, dest_bitmap␍␊
Parameters
src_type - EDID source type (usually output) (see Section 6.3 EDID Source)
src_id - number of chosen source stage (1.. max number of inputs/outputs)
dst_type - EDID destination type (usually input) (see Section 6.3 EDID Source)
dest_bitmap - bitmap representing destination IDs. Format: XXXX…X, where X is hex digit. The binary
form of every hex digit represents corresponding destinations. Setting ‘1’ says that EDID data has to be
copied to this destination
Response Triggers
Response is sent to the com port from which the Set was received (before execution)
Notes
Destination bitmap size depends on device properties (for 64 inputs it is a 64-bit word)
Example: bitmap 0x0013 means inputs 1,2 and 5 are loaded with the new EDID
