VM-8HN - Overview

3 Overview

The VM-8HN is a high-quality 1:8 HDMI distributor with 2 looping HDMI outputs

that takes one HDMI input, equalizes and reclocks the signal and distributes it to

eight identical outputs and two loops. The VM-8HN distributes signals having

resolutions up to 4Kx2K 30Hz and including WUXGA and 1080p.

In particular, the VM-8HN features:

 A maximum data rate of 10.2Gbps (3.4Gbps per graphic channel)

 HDMI support for Deep Color, x.v.Color™, Lip Sync, HDMI Uncompressed

Audio Channels, Dolby TrueHD, DTS-HD, CEC (CEC pass through from

input to output 1 only)

 HDCP compliance

 Video wall support with selectable output delay

 Automatic 5V turn off for remotely powering off attached devices

 Kramer Equalization & re-Klocking™ Technology that rebuilds the digital

signal integrity to travel longer distances

 I-EDIDPro™ Kramer Intelligent EDID Processing™, an intelligent EDID

handling and processing algorithm that ensures Plug and Play operation for

HDMI systems

 A default EDID for fast and efficient connection of the unit

The default EDID feature lets you connect the VM-8HN without having to connect a

display to the output

 Support for EDID Designer

 3D pass-through

3.1 Defining the VM-8HN 1:8+2 HDMI Looping DA

This section defines the VM-8HN.
