2 RC-13TC - Getting Started
2 Getting Started
We recommend that you:
• Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
• Review the contents of this user manual
• Use Kramer high-performance high-resolution cables
Go to http://www.kramerelectronics.com to check for up-to-date
user manuals, application programs, and to check if firmware
upgrades are available (where appropriate).
This user manual is written for the end user and does not contain details regarding
installation and configuration. This information can be found in the K-Config
Configuration Guide, available from
http://www.kramerelectronics.com.
2.1 Achieving the Best Performance
To achieve the best performance:
• Use only good quality connection cables to avoid interference, deterioration
in signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
• Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
• Position your Kramer RC-13TC away from moisture, excessive sunlight and
dust
Caution: No operator serviceable parts inside the unit
Warning:
Disconnect the power and unplug the unit from the wall
before installing
i
!
