RC-13TC - Overview 3
3 Overview
This user manual describes the RC-13TC Video Transport Controller. The
RC-13TC controller interface acts as an all-in-one, remote control panel for several
AV sources in any venue, such as, classrooms, boardrooms or auditoriums. The
RC-13TC streamlines operations by enabling remote transport control of the video
source in the room. The RC-13TC features:
• Programmable, backlit buttons (configurable by your system integrator) that
are able to execute one or multiple commands (programming performed by
your system integrator)
• A bidirectional RS-232 serial port for control of AV equipment
• Two K-NET™ ports
• Two IR control ports
• Support for firmware upgrade via USB or the K-NET™ connection (when
installed as an auxiliary device)
