4 RC-13TC - Defining the RC-13TC Video Transport Controller
4 Defining the RC-13TC Video Transport
Controller
This section defines the RC-13TC.
Figure 1: RC-13TC Video Transport Controller Front Panel
# Feature Function
1 Source Select Button Press to select the AV source
2 Video Transport Control Buttons Use to control the functions of the selected AV
source
3 LCD Programmable Readout
Programmable, 8-character LCD readout with white
characters on a blue background (which usually
reflects the selected AV source name)
