EDID Designer - Installing EDID Designer
5
The latest version of the device adapters downloads from the Web. Allow it
to run to completion the first time otherwise device adapters or their latest
versions might not be available for use.
To launch EDID Designer:
Click Start and click on the application.
The EDID Designer main screen opens (see Figure 1) and automatically
updates device adapters.
