![Kramer VP-553 [24/81] The audio parameters](/views2/1153519/page24/bg18.png)
VP-553 - Controlling the VP-553
19
19
Mode
Function
OUTPUT
HDCP
Select FOLLOW INPUT or FOLLOW OUTPUT to define whether the HDCP
will follow the input or the output
When FOLLOW INPUT is selected, it changes its HDCP output setting (for
the HDMI output) according to the HDCP of the input. This option is
recommended when the HDMI output is connected to a splitter/switcher
When FOLLOW OUTPUT is selected, the scaler matches its HDCP output
to the HDCP setting of the HDMI acceptor to which it is connected
AUTOSYNC
OFF
Turn the auto sync ON/OFF. When ON, this de-activates the output after a few
minutes if no input is present.
This is useful, for example, when the output is connected to a projector, and the
projector will automatically shut down when it has no input
AUDIO
Adjust audio parameters (see Section 6.2.2.1)
AUDIO EQ
Set the audio EQ values in 0.5dB steps for: BELOW 120Hz, CENTER 200Hz,
CENTER 500Hz, CENTER 1200Hz, CENTER 3000Hz, CENTER 7500Hz and
ABOVE 12000Hz
NO SIGNAL
COLOR
Select a BLUE or BLACK window color if no signal is detected
PC
AUTO ADJUST
When set to ON, auto adjusts the image (centers it
correctly on the screen) every time the input is switched to
VGA or when the input resolution changes
H-POSITION
Set the horizontal position of the picture
V-POSITION
Set the vertical position of the picture
PHASE
Set the clock phase
CLOCK
Set the clock frequency
WXGA/XGA
Set to WXGA or XGA
RESET
Reset settings to their default values
6.2.2.1 The AUDIO Parameters
Parameter
Function
SOURCE
Select the audio source: FOLLOW VIDEO, HDMI1, HDMI2, HDMI3,
HDBT1, HDBT2, HDBT3, PC1, PC2, TP1, TP2, CV1, CV2, or MIC
EMBEDDED AUDIO
HDMI AUDIO IN
(1, 2 and 3)
Select the HDMI 1, HDMI 2 and HDMI 3 audio
sources behavior:
AUTOMATIC: the embedded audio on the HDMI
input is selected for an HDMI signal, or the analog
audio input is selected if the input is not HDMI (for
example, for a DVI input signal)
EMBEDDED: the embedded audio in the HDMI
signal is selected
ANALOG: the analog audio input is selected
HDMI AUDIO IN is enabled only when one of the
HDMI inputs is selected
OUTPUT VOLUME
Set the output volume
MUTE
Set MUTE to ON or OFF
DELAY
Select the audio delay time: OFF, 10ms to 80ms in 10ms steps or
DYNAMIC
MICROPHONE MIX
Set mix ON to mix the microphone input with the selected audio input
or set to OFF
MIX LEVEL
Adjust the mix level (enabled when MICROPHONE MIX is set to ON)
