Using the K-Able Box

6 Using the K-Able Box

6.1 Extending the Cable

To extend the cable:

1. Extend the free end of the cable until the required length is exposed.

2. Extend the cable a short distance further until you feel increased

tension.

3. Release the cable.

The lock engages and prevents the cable from retracting.

6.2 Retracting the Cable

To retract the cable:

1. Extend the cable a short distance until you feel decreased tension.

The lock is disengaged.

2. Allow the cable to retract keeping it under a light tension.

When the lock disengages, do not let go of the cable and allow it to

retract unrestrained or the mechanism/cable may be damaged.

In the event that there is a problem with getting the cable to retract, extend

the cable fully and the mechanism will disengage.

6.3 Storing the Fixed End of the Cable

Wind the fixed end of the cable around the external spool for storage.

7 Connecting the K-Able Box

To connect the K-Able Box:

1. Connect the fixed cable end to the cable infrastructure of the room (for

example, leading to a projector).

2. Pull the extendable cable end and connect it to the source (for example,

a laptop).
