5.5 Connecting the Cables

When replacing blank inserts with connector inserts (for example, VGA, audio,

HDMI and so on):

1. Insert the cables to their appropriate connectors from underneath.

2. Secure the cables to the tie holes using the included self-locking ties.

Do not secure the cables too tightly or too loosely. Leave a small amount of

slack.

After the TBUS-4xl is connected to mains power and the proper cables, it is ready for

use.

5.6 Inserting the Pass-through Cables

To insert the pass-through cables, for example, to connect a laptop, do the

following (see

Figure 3):

1. Remove the two screws attaching the split pass-through bracket.

2. Remove the split grommet.

3. Insert the cable through the rectangular opening.

4. Open the split grommet slightly and insert the required cables.

5. Place the split bracket around the grommet and position this assembly over

the Inner Frame.

6. Place the two screws appropriately and tighten the split bracket together

with the grommet and inserted cables to the inner frame.

7. Insert the self-locking ties through the tie holes to secure the cables to the

inside walls of the enclosure.
