Kramer TBUS-4xl [6/20] Overview

TBUS-4xl - Overview 3

3 Overview

The Kramer TBUS-4xl is a high-quality, anodized aluminum, table-mounted

connection bus enclosure for boardrooms and conference rooms. Its attractive

enclosure is designed to provide maximum connectivity in the smallest possible

footprint. The unit is sturdy, cost-effective, and easy to install.

TBUS-4xl features:

• A modular design, letting you tailor the TBUS-4xl according to your

requirements

• A black anodized or brushed clear aluminum lid with a special opening for

cable pass-through (note, that other customized colors can also be ordered)

• Height adjustment screw holes to set the inner frame (ordered separately) to

the desired height

• Power socket openings that are suitable for any of the following power

sockets: for the USA, Germany (the Europlug), Belgium-France, Italy,

Australia, Israel, South Africa or “Universal” for use anywhere (see

compatibility restrictions in

Section 7

Order the power sockets separately from Kramer Electronics

)

• An optional insert kit to replace one power socket

The insert kit can include two wall plate module inserts, two cable pass-through

connectors, or one of each

TBUS-4xl is height-adjustable and the cover opens and closes manually, keeping

the cables and the connectors out of sight when not used.

Figure 1: TBUS-4xl inside a Table

Do not place heavy objects on top of the TBUS-4xl.
