8 TBUS-6xl - Installing the TBUS-6xl

5 Installing the TBUS-6xl

To install the TBUS-6xl perform the following steps:

1. Assemble the inner frame (see

Section 5.1

2. Install the inner frame (see

Section 5.2

3. Cut an opening in the table (see

Section 5.3

4. Insert the unit through the opening and secure to the table (see

Section 5.4

5. Connect the cables (see

Section 5.5

6. Insert pass-through cables (see

Section 5.6

7. Adjust the height of the inner frame (see

)

Section 5.7

5.1 Assembling the Inner Frame

The modules mounted on the inner frame can include single inserts and/or dual

inserts as well as a power socket (in some models). This section describes how to

assemble these modules.

Each module kit comes with detailed assembly instructions.

5.1.1 Mounting the Inserts

You can rearrange or remove any of the plates mounted on the inner frame and

replace them with Kramer passive wall plates or connector modules for interfacing

A/V type signals.

To mount a Kramer insert or connector module:

1. Unscrew the two screws that fasten the blank plate to the inner frame and

remove the blank plate.

2. Place the required Kramer insert over the opening, insert the two screws to

fix the Kramer insert in place, and tighten them.
