TBUS-6xl - Overview 3
3
3 Overview
The Kramer TBUS-6xl is a high-quality, anodized aluminum, table-mounted
connection bus enclosure for boardrooms and conference rooms. Its attractive
enclosure is designed to provide maximum connectivity in the smallest possible
footprint. The unit is sturdy, cost-effective, and easy to install.
The TBUS-6xl includes:
• A modular design, letting you tailor the TBUS-6xl according to your
requirements
• A black anodized or brushed clear aluminum lid with a special opening for
cable pass-through (note, that other customized colors can also be ordered)
• Height adjustment screw holes to set the inner frame (ordered separately) to
the desired height
• Power socket openings that are suitable for any of the following power
sockets: for the USA, Germany (the Europlug), Belgium-France, Italy,
Australia, Israel, South Africa or “Universal” for use anywhere (see
compatibility restrictions in
Section 7
Order the power sockets separately from Kramer Electronics
)
• An optional insert kit to replace one power socket
The insert kit can include two wall plate module inserts, two cable pass-through
connectors, or one of each
The TBUS-6xl is height-adjustable. The cover that opens and closes manually
retracts into the unit to remain out of sight when the TBUS-6xl is in use. When
closed, all cables and connectors are out of sight under the anodized cover.
!
Do not place heavy objects on top of the TBUS-6xl.
