16 TBUS-6xl - Technical Specifications of the Assembled TBUS-6xl
7 Technical Specifications of the Assembled
TBUS-6xl
POWER SOURCE
(AC power limits):
Power Socket Assemblies
Universal 100-240V AC, 50/60Hz, 5A
Maximum 5A per power outlet
Fully compatible with power plugs in the UK, India, Italy
and Denmark, as well as with the 2-prong Europlug.
Partially compatible (if the polarity is reversed) with plugs
in China, Switzerland, Israel and the USA. The universal
socket does not supply grounding to plugs in Central
Europe and France (you should order country specific
sockets instead).
Not compatible with South African plugs.
USA 100-240V AC, 50/60Hz, 5A
Maximum 5A per power outlet
Germany and EU 100-240V AC, 50/60Hz, 5A
Maximum 5A per power outlet
Belgium and France 100-240V AC, 50/60Hz, 5A
Maximum 5A per power outlet
South Africa 100-240V AC, 50/60Hz, 5A
Maximum 5A per power outlet
Australia 100-240V AC, 50/60Hz, 5A
Maximum 5A per power outlet
Israel
220V AC, 50/60Hz, 5A
Maximum 5A per power outlet
South Africa
220V AC, 50/60Hz, 5A
Maximum 5A per power outlet
FUSE RATING: T 6.3A 250V
OPERATING TEMPERATURE
RANGE:
+5 to +45 Deg. Centigrade
OPERATING HUMIDITY
RANGE:
10 to 90% RHL, non-condensing
STORAGE TEMPERATURE
RANGE:
-20 to +70Deg. C.
STORAGE HUMIDITY RANGE: 5 to 95% RHL, non-condensing
DIMENSIONS: Top plate: 243mm x 140.4mm (9.6" x 5.5") W, D
Enclosure: 203mm x 102mm x 130mm (8.0" x 4.0" x 5.1")
W, D, H
WEIGHT: TBUS-6: 2.03kg (4.48lbs) approx.
Table clamps: 0.25kg (0.6lbs)
ACCESSORIES: Power cord, four self-locking ties, template, template
screws
OPTIONS: Inner frames, passive wall plates and interfaces, power
socket kits, power cord
Specifications are subject to change without notice at http://www.kramerelectronics.com
