35
English
Z97M OC Formula
3.2 Formula Drive
Formula Drive is ASRock’s multi purpose soware suite with a new interface, more
new features and improved utilities, including XFast RAM, Dehumidier, Good
Night LED, FAN-Tastic Tuning, OC Tweaker and a whole lot more.
3.2.1 Installing Formula Drive
When you install the all-in-one driver to your system from ASRock’s support
CD, Formula Drive will be auto-installed as well. Aer the installation, you will
nd the icon “Formula Drive“ on your desktop. Double-click the “Formula Drive“
icon, Formula Drive main menu will pop up.
3.2.2 Using Formula Drive
ere are six sections in Formula Drive main menu: Operation Mode, Tools, OC
Tweaker, System Info, Live Update, Tech Service and Settings.
Operation Mode
Choose an operation mode for your computer.
